Sel 411L - Figure 8.4 Sample COMTRADE.HDR Header File

P.8.9
Date Code 20151029 Protection Manual SEL-411L Relay
Oscillography, Events, and SER
Oscillography
Figure 8.4 Sample COMTRADE .HDR Header File
.CFG File
The .CFG file contains data such as sample rates, number of channels, line
frequency, channel information, and transformer ratios (see Figure 8.5). A
<CR><LF> follows each line. If control inputs or control outputs are not
available because of board loading and configuration, the relay does not report
these inputs and outputs in the analog and digital sections of the .CFG file.
Relay 1 Date: 02/02/2011 Time: 14:11:21.000
Station A Serial Number: 2010265004
Event: ABG T Location: 59.61 (mi) From: LOCAL FLM: TW Time Source: HIRIG
Event Number: 10121 Shot 1P: 0 Shot 3P: 0 Freq: 59.99 Group: 1
Targets:
Breaker 1: CLOSED
Breaker 2: OPEN
PreFault: IA IB IC IG 3I2 VA VB VC V1mem
MAG(A/kV) 200 200 200 1 1 133.946 133.938 133.941 133.935
ANG(DEG) -0.7 -120.5 119.4 -51.7 -88.7 0.0 -119.9 120.2 0.1
Fault:
MAG(A/kV) 2200 2200 2200 7 376 133.937 133.926 133.957 133.933
ANG(DEG) -0.7 -120.6 119.5 -102.0 -83.5 0.0 -119.9 120.2 0.1
87 Differential Currents
PreFault: IA IB IC IQ IG
MAG(pu) 0.00 0.00 0.00 0.00 0.00
ANG(DEG) 0.0 0.0 0.0 0.0 0.0
Fault:
MAG(pu) 0.00 0.00 0.00 0.00 0.00
ANG(DEG) 0.0 0.0 0.0 0.0 0.0
SET_G1.TXT
[INFO]
RELAYTYPE=SEL-411L
FID=SEL-411L-X136-V0-Z001001-D20110114
BFID=SLBT-4XX-R205-V0-Z001002-D20100128
PARTNO=0411L0X6X1B6BCXH5C4E4XX
[IOBOARDS]
INT4_E, , , 24, 8, 0, 0, 1
CFSINT8, , , 8, 8, 0, 0, 2
[G1]
"SID","Station A"
"RID","Relay 1"
"NUMBK",2
"BID1","Breaker 1"
"BID2","Breaker 2"
"NFREQ",60
.
.
.
"AR197",
"AR198",
"AR199",
"AR200",
Summary Event
Information
Relay Settings
