Sel 411L - Table 15.69 Accessible GOOSE IED Information

P.15.25
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
The information displayed for each GOOSE IED is described in Table 15.69.
Table 15.69 Accessible GOOSE IED Information
IED Description
Transmit GOOSE
Control Reference
This field represents the GOOSE control reference information that
includes the IED name, ldInst (Logical Device Instance), LN0
lnClass (Logical Node Class), and GSEControl name (GSE
Control Block Name) (e.g., SEL_411L_OtterCFG/LLN0$DSet13).
Receive GOOSE
Control Reference
This field shall contain the goCbRef (GOOSE Control Block
Reference) information that includes the iedName (IED name),
ldInst (Logical Device Instance), LN0 lnClass (Logical Node
Class) and cbName (GSE Control Block Name) (e.g.,
SEL_411L_1CFG/LLN0$DSet13)
Multicast Address
(MultiCastAddr)
This hexadecimal field represents the GOOSE multicast address.
Priority Tag (Ptag) This three-bit decimal field represents the priority tag value, where
spaces are used if the priority tag is unknown.
VLAN (Vlan) This 12
-bit decimal field represents the virtual LAN (Local Area
Network) setting, where spaces are used if the virtual LAN is
unknown.
State Number
(StNum)
This hexadecimal field represents the state number that increments
with each state change.
Sequence Number
(SqNum)
This hexadecimal field represents the sequence number that
increments with each GOOSE message sent.
Time to Live (TTL) This field contains the time (in ms) before the next message is
expected.
Code This text field indicates warning or error conditions that are
abbreviated as follows:
Code Abbreviation Explanation
OUT OF SEQUENC Out of sequence error
CONF REV MISMA Configuration Revision mismatch
NEED COMMISSIO Needs Commissioning
TEST MODE Test Mode
MSG CORRUPTED Message Corrupted
TTL EXPIRED Time to live expired
HOST DISABLED Optional code for when the host is
disabled or becomes unresponsive after
the GOOSE command has been issued.
Transmit Data Set
Reference
This field represents the datSetRef (Data Set Reference) that
includes the IED name, LN0 lnClass (Logical Node Class), and
GSEControl datSet (Data Set Name) (e.g., SEL_411L_1CFG/
LLN0$DSet13).
Receive Data Set
Reference
This field represents the datSetRef (Data Set Reference) that
includes the iedName (IED name), ldInst (Logical Device
Instance), LN0 lnClass (Logical Node Class) and datSet (Data Set
Name) (e.g., SEL_411L_1CFG/LLN0$DSet13).
