P.5.2
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Alias Settings
➢ Settings group selection
➢ Data reset control
➢ Frequency estimation
➢ Time-error calculation
➢ Current and voltage source selection
➢ Synchronized phasor measurement
➢ DNP3
➤ Protection Free-Form SELOGIC Control Equations on
page P.5.9
➤ Automation Free-Form SELOGIC Control Equations on
page P.5.9
➤ Notes Settings on page P.5.10
➤ Output Settings on page P.5.10
➢ Interface board outputs
➢ Ethernet card outputs
➢ MIRRORED BITS
®
communications transmit equations
➤ Port Settings on page P.5.18
➢ Ports 1, 2, 3, F, and 5
➤ DNP3 Settings—Custom Maps on page P.5.25
Alias Settings
Assign a valid seven-character alias name to any of the following:
➤ Relay Word bit (except target LEDs)
➤ Analog Quantity
Invalid alias names include the following keywords used by settings and
SEL
OGIC control equations:
➤ END
➤ INSERT
➤ DELETE
➤ LIST
➤ NA
➤ Off
SEL
OGIC control equation operators (e.g., NOT, AND, OR, COS) cannot be
used as alias names.
Alias names are valid when the following are true:
➤ They consist of a maximum of seven characters.
➤ They are constructed using characters 0–9, uppercase A–Z, or
the underscore (_).
For example, the default name for contact output OUT201 is OUT201. You
could change the default name to an alias, BK1 Trip, for example.
