Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Alias Settings
BK1 Trip (including the space) consists of eight characters, one more than the
allowable number of seven. Changing the name to BK1 Tr reduces the
character count to six, but the alias contains two elements not permitted, a
space and one lowercase letter (r). One possible alias for the existing name of
OUT201 could be BK1_TR, entered using the following syntax:
primitive name, alias name,
e.g., OUT201, BK1_TR
Figure 5.1 shows the steps using the SET T command.
=>>SET T <Enter>
Alias
Relay Aliases
(RW Bit or Analog Qty. 7 Character Alias [0-9 A-Z _])
1: EN,"RLY_EN"
? <Enter>
2:
? OUT201, BK1_TR
3:
? END <Enter>
Alias
Relay Aliases
(RW Bit or Analog Qty. 7 Character Alias [0-9 A-Z _])
1: EN,"RLY_EN"
2: OUT201,"BK1_TR"
.
.
.
Save settings (Y,N) ?Y <Enter>
Saving Settings, Please Wait...........
Settings Saved
=>>
Figure 5.1 Changing a Default Name to an Alias
Table 5.2 Default Alias Settings (Sheet 1 of 2)
Label Default Value
EN RLY_EN
TLED_1 INST
TLED_2 TIME
TLED_3 COMM
TLED_4 SOTF
TLED_5 ZONE_1
TLED_6 ZONE_2
TLED_7 ZONE_3
TLED_8 ZONE_4
TLED_9 A_PHASE
TLED_10 B_PHASE
TLED_11 C_PHASE
TLED_12 GND
TLED_13 87L
TLED_14 87L_LST
TLED_15 87L_ALM
TLED_16 N_A
TLED_17 79_RST
TLED_18 79_LO
