Sel 411L - Front-Panel Settings; Table 5.22 Remote Analog Outputs; Table 5.24 87 L Communication Bits Transmit Equations; Table 5.25 Front-Panel Settings Categories

P.5.11
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Front-Panel Settings
Make Table 5.22 settings if an Ethernet card is present and IEC 61850 is ordered.
Front-Panel Settings
Table 5.22 Remote Analog Outputs
Label Prompt Default Value
RAO01 NA
•
•
•
•
•
•
•
•
•
RAO64 NA
Ta b l e 5. 2 3 M
IRRORED BITS Transmit Equations
Label Prompt Default Value
TMB1A NA
•
•
•
•
•
•
•
•
•
TMB8A NA
TMB1B NA
•
•
•
•
•
•
•
•
•
TMB8B NA
Table 5.24 87L Communication Bits Transmit Equations
Label
a
,
b
a
x = 1–4. These settings are hidden when E87CH = N or 2E or 3E or 4E. Also hidden if there is
no serial communications card installed.
b
nn = 01–32. These settings are visible when E87CH = 2E, 3E or 4E, and are hidden in all other cases.
Prompt Default Value
87TxP1 • NA
87TxP2 • NA
87TnnE•NA
Table 5.25 Front-Panel Settings Categories
Settings Reference
Front-Panel Settings Table 5.26
Selectable Screens for the Front Panel Table 5.27
Selectable Operator Pushbuttons Table 5.28
Front-Panel Event Display Table 5.29
Local Control and Aliases Table 5.32
Display Points and Aliases
Boolean Display Points Table 5.30
Analog Display Points Table 5.31
NOTE: See corresponding command
descriptions SET F on page P.15.47 to
set or show the Front-Panel settings.
