P.15.23
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
EVE Sx
Use the EVE Sx command to specify the sample data resolution of the event
report. The sample data resolution x is either 4 samples/cycle or 8 samples/
cycle; the default value is 4 samples/cycle if you do not specify Sx. The Sx
option overrides the L option.
EVE Command Option Combinations
You can combine options C, L, Lyyy, n, NSET, NSUM, and Sx, in one
command. Enter the options according to the following guidelines:
➤ The Lyyy option overrides the C option.
➤ The Sx option overrides the L option.
➤ When choosing option A or option D as a report type, you
cannot use option C to specify the report length at 15 cycles.
Use option Lyyy at L015 to specify a 15-cycle report.
➤ Enter the options in any order.
Table 15.64 lists the choices you can make in the EVE command. Combine
options on each row, selecting one option from each column, to create an EVE
command.
The following examples illustrate some possible option combinations.
Table 15.63 EVE Sx Command
Command
a
a
Parameter n indicates event order or serial number; x is 4 or 8 to represent data at 4
samples/cycle or 8 samples/cycle, respectively.
Description Access Level
EVE Sx Return the most recent event report at full
length with x-samples/cycle data.
1, B, P, A, O, 2
EVE n Sx Return a particular n event report at full length
with x
-samples/cycle data.
1, B, P, A, O, 2
Table 15.64 EVE Command Option Groups
Acknowledge
Event
Number
Data
Resolution
Report
Type
Report
Length
Omit
ACK
n, NEXT Sx, L C, A, D Lyyy, C NSET,
NSUM
Table 15.65 EVE Command Examples
Example Description
EVE L010 S8 Return 10 cycles of an 8-samples/cycle event report for the most
recent event.
EVE L10 A Return 10 cycles of the analog portion only of the most recent
event report at 4
-samples/cycle resolution.
EVE 2 C NSUM For the second most recent event, return the event with 8
-samples/
cycle data, and omit the event summary.
