Description of Commands
SET D
Issue the SET D command to remap the DNP3 values. To set the general DNP
settings, use the Port settings for the appropriate port. There are five instances
of the DNP3 remapping settings so you may specify which instance to set.
SET F
Use the SET F command to set the relay front-panel settings. There is only
one instance for the front-panel settings. See Section 7: Front-Panel
Operations for information about front-panel settings.
SET G
Use the SET G command to the Global class settings. There is only one
instance for the Global class.
SET L
Use the SET L command to set the Protection SELOGIC control equations.
See Section 14: SEL
OGIC Control Equation Programming for more
information on SEL
OGIC control equations.
Ta b l e 1 5.1 1 7 S E T D Co m m a nd
Command Description Access Level
SET D Set the DNP3 remapping settings, beginning at
the first setting in this class for instance 1.
P, A, O, 2
SET D label Set the DNP3 remapping settings, beginning at
setting label.
P, A, O, 2
SET D instance Set the DNP3 remapping settings beginning at
the first setting of instance.
P, A, O, 2
Table 15.118 SET F Command
Command Description Access Level
SET F Set the front-panel relay settings, beginning at the first
setting in this class.
P, A, O, 2
SET F label Set the front-panel relay settings, beginning at the
settings label label.
P, A, O, 2
Ta b l e 1 5.1 1 9 S E T G Co m m an d
Command Description Access Level
SET G Set the Global relay settings, beginning at the first
setting in this class.
P, A, O, 2
SET G label Set the Global relay settings, beginning at the setting
label label.
P, A, O, 2
Ta b l e 1 5.1 20 S E T L C om m a n d
Command
a
a
Parameter n is 1–6 for Protection Groups 1–6.
Description Access Level
SET L Set the Protection SELOGIC control equation relay
settings for the active settings group.
P, 2
SET L n Set the Protection SEL
OGIC relay settings for Instance n,
which is Group n.
P, 2
