Sel 411L - Figure 8.11 Summary Section of the Event Report

P.8.23
Date Code 20151029 Protection Manual SEL-411L Relay
Oscillography, Events, and SER
Event Reports, Event Summaries, and Event Histories
Figure 8.11 Summary Section of the Event Report
Settings Section of the Event Report
The final portion of an event report is the settings section. See Figure 8.12 for
the locations of items included in a sample settings section of an event report.
If you want to exclude the settings portion from an event report, use the EVE
NSET command.
The settings portion of the event report lists important relay settings at the
time the relay event triggered. The event report shows group, global, output,
protection SEL
OGIC control equation settings and alias settings. For the group
settings and the protection SEL
OGIC settings, the relay reports only the active
group. The settings order in the event report is the same order as when you
issue a SHOW command from a terminal.
Event: TRIP Location: $$$$.$$ From: LOCAL FLM: SE Time Source: OTHER
Event Number: 10030 Shot 1P: 0 Shot 3P: 0 Freq: 60.00 Group: 1
Targets: INST COMM 87L
Breaker 1: CLOSED Trip Time: 11:18:49.016
Breaker 2: NA
PreFault: IA IB IC IG 3I2 VA VB VC V1mem
MAG(A/kV) 426 426 427 1 0 286.420 286.638 286.302 286.453
ANG(DEG) 1.3 -118.7 121.3 130.6 -99.2 0.0 -120.0 120.0 0.0
Fault:
MAG(A/kV) 426 426 427 1 1 286.397 286.632 286.298 286.450
ANG(DEG) 1.3 -118.7 121.3 106.1 -92.6 0.0 -120.0 120.0 0.0
87 Differential Currents
PreFault: IA IB IC IQ IG
MAG(pu) 0.36 0.35 0.36 0.00 0.00
ANG(DEG) 1.4 -118.9 120.9 92.9 59.5
Fault:
MAG(pu) 0.00 0.00 0.00 0.00 0.00
ANG(DEG) -20.6 -20.6 -20.6 -20.6 -20.6
Event Information
Prefault Data
Fault Data
Line Current Differential Status
Group 1
Line Configuration
CTRW : 400 CTRX : 400 PTRY : 3636 VNOMY : 115
PTRZ : 3636 VNOMZ : 115 Z1MAG : 4.72 Z1ANG : 82.60
Z0MAG : 14.50 Z0ANG : 75.70 EFLOC : Y
Global
General Global Settings
SID : "Station A"
RID : "Relay 1"
NUMBK : 2
BID1 : "Breaker 1"
BID2 : "Breaker 2"
NFREQ : 60 PHROT : ABC DATE_F : MDY
FAULT : NA
Output
Interface Board #1
OUT201 : 3PT
OUT202 : BK1CL
OUT203 : BK2CL
OUT204 : NA
OUT205 : NA
OUT206 : NA
OUT207 : NA
OUT208 : NA
Active Group Settings
•
•
•
•
•
•
•
•
•
Global Settings
Output Settings
