Event Reports, Event Summaries, and Event Histories
Event Reporting Analog Quantities
(Maximum 20 Analog Quantities)
1: PMV01
2: PMV02
3: PMV03
4: PMV04
5: PMV05
6: PMV06
The relay correlates the free-form line number chronologically with the
ERAQc quantities. In this example, ERAQ01 = PMV01, ERAQ02 = PMV02,
etc.
In the event report, the ERAQ quantities follow the fixed analog quantities.
PMV01 PMV02 PMV03 PMV04 PMV05 PMV06
[1]
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
[2]
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
20.000 25.000 102.000 34.000 67.000 54.000
Digital Section INnnn Times
Reported assertion times for input digital elements differ, although these
elements have the same name in both high-resolution raw data reports and in
the filtered event reports. When you enter an input (INnnn) in the event
digitals list, the relay displays the filtered input with time latency in the event
report and the Compressed ASCII event report. However, in the binary
COMTRADE file event report, the relay reports the actual high-sample rate
capture time for relay inputs.
Event Summary Section of the Event Report
The third portion of an event report is the summary section. See Figure 8.11
for the locations of items included in a sample summary section of an event
report. If you want to exclude the summary portion from an event report, use
the EVE NSUM command.
The information in the summary portion of the event report is the same
information in the event summary, except that the report header does not
appear immediately before the event information when you view a summary
in the event report.
Setting Description Range Default Category
ERAQc Free form See Section 17: Analog Quantities NA Report
