Sel 411L - Table 5.42 MIRRORED BITS Protocol Settings

P.5.22
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Port Settings
.
Ta b l e 5. 4 2 M IRRORED BITS Protocol Settings
Label Prompt Default Value
TX_ID MIRRORED BITS ID of This Device (1–4) 2
RX_ID M
IRRORED BITS ID of Device Receiving From (1–4) 1
RBADPU Outage Duration to Set RBAD (0–10000 s) 10
CBADPU Channel Unavailability to Set CBAD (1–100000 ppm) 20000
TXMODE Transmission Mode (N-Normal, P-Paced) N
MBNUM Number of M
IRRORED BITS Channels (0–8) 8
RMB1FL RMB1 Channel Fail State (0, 1, P) P
RMB1PU RMB1 Pickup Time (1–8 messages) 1
RMB1DO RMB1 Dropout Time (1–8 messages) 1
RMB2FL RMB2 Channel Fail State (0, 1, P) P
RMB2PU RMB2 Pickup Time (1–8 messages) 1
RMB2DO RMB2 Dropout Time (1–8 messages) 1
RMB3FL RMB3 Channel Fail State (0, 1, P) P
RMB3PU RMB3 Pickup Time (1–8 messages) 1
RMB3DO RMB3 Dropout Time (1–8 messages) 1
RMB4FL RMB4 Channel Fail State (0, 1, P) P
RMB4PU RMB4 Pickup Time (1–8 messages) 1
RMB4DO RMB4 Dropout Time (1–8 messages) 1
RMB5FL RMB5 Channel Fail State (0, 1, P) P
RMB5PU RMB5 Pickup Time (1–8 messages) 1
RMB5DO RMB5 Dropout Time (1–8 messages) 1
RMB6FL RMB6 Channel Fail State (0, 1, P) P
RMB6PU RMB6 Pickup Time (1–8 messages) 1
RMB6DO RMB6 Dropout Time (1–8 messages) 1
RMB7FL RMB7 Channel Fail State (0, 1, P) P
RMB7PU RMB7 Pickup Time (1–8 messages) 1
RMB7DO RMB7 Dropout Time (1–8 messages) 1
RMB8FL RMB8 Channel Fail State (0, 1, P) P
RMB8PU RMB8 Pickup Time (1–8 messages) 1
RMB8DO RMB8 Dropout Time (1–8 messages) 1
MBTIME Accept M
IRRORED BITS Time Synchronization (Y, N) N
MBNUMAN Number of Analog Channels (0–7) 0
MBANA1 Selection for Analog Channel 1 (analog label) LIAFM
MBANA2 Selection for Analog Channel 2 (analog label) LIBFM
MBANA3 Selection for Analog Channel 3 (analog label) LICFM
MBANA4 Selection for Analog Channel 4 (analog label) VAFM
MBANA5 Selection for Analog Channel 5 (analog label) VBFM
MBANA6 Selection for Analog Channel 6 (analog label) VCFM
MBANA7 Selection for Analog Channel 7 (analog label) VABRMS
MBNUMVT Number of Virtual Terminal Channels (OFF, 0–7) OFF
