P.A.8
SEL-411L Relay Protection Manual Date Code 20151029
Firmware and Manual Versions
SEL
BOOT
SELBOOT
SELBOOT is a firmware package inside the relay that handles hardware
initialization and provides the functions needed to support firmware upgrades.
To determine the SEL
BOOT version, view the status report by using the serial
port STATUS command or the front panel. The device will report the
SEL
BOOT firmware identification (BFID) label as:
BFID=SLBT-4XX-Rxxx-Vx-Zxxxxxx-Dxxxxxxxx
Table A.3 lists the SEL
BOOT releases used with the SEL-411L, their revisions
and a description of modifications. The most recent SEL
BOOT revision is
listed first.
ICD File
Determining the ICD
File Version in Your
Relay
To find the ICD revision number in your relay, view the configVersion using
the serial port ID command. The configVersion is the last item displayed in the
information returned from the ID command.
configVersion = ICD-411L-R102-V0-Z000000-D20130619
The ICD revision number is after the R (e.g., 201) and the release date is after
the D. This revision number is not related to the relay firmware revision
number. The configVersion revision displays the ICD file version used to
create the CID file that is loaded in the relay.
NOTE: The Z number representation
is implemented with ClassFileVersion
002. Previous ClassFileVersions do
not provide an informative Z number.
The configVersion contains other useful information. The Z number consists
of six digits. The first three digits following the Z represent the minimum IED
firmware required to be used with the ICD (e.g., 307). The second three digits
represent the ICD ClassFileVersion (e.g., 005). The ClassFileVersion increments
when there is a major addition or change to the 61850 implementation of the relay.
Table A.4 list the ICD file versions, a description of modifications, and the
instruction manual date code that corresponds to the versions. The most recent
version is listed first.
NOTE: All revisions of SELBOOT
listed in this table are compatible
with all versions of firmware
available for this relay.
Ta b l e A . 3 SE LBOOT Revision History
SELBOOT Firmware Identification (BFID) Summary of Revisions
SLBT-4XX-R209-V0-Z001002-D20150130
➤ Added support for a new main board variant.
➤ Modified the firmware to prevent an issue that could cause the relay to become
unresponsive.
SLBT-4XX-R208-V0-Z001002-D20120220
➤ Added support for a new main board variant.
SLBT-4XX-R207-V0-Z001002-D20110922
➤ First revision used with SEL-411L.
Table A.4 SEL-411L ICD File Revision History
configVersion
a
Summary of Revisions
Minimum
Relay
Firmware
ClassFile
Version
Manual
Date Code
ICD-411L-R200-V0-Z117005-D20150415 Added support for 61850 group switch, Simu-
lated Goose and stSeld.
R117 005 20150626
ICD-411L-R103-V0-Z111005-D20150408 Enforced the 512 Boolean limit across all
GOOSE messages
R111 005 20150626
