Sel 411L - Table 5.5 Global Enables; Table 5.6 Station DC1 Monitor (and Station DC2 Monitor); Table 5.7 Control Inputs; Table 5.8 Interface Board #1 Control Inputs

P.5.5
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Global Settings
Make Table 5.6 settings when Global enable setting EDCMON := 1 or 2.
These settings are hidden when EDCMON := N.
Make Table 5.7 settings when Global enable setting EICIS := N.
Make Table 5.8 settings for Interface Board #1 when Global enable setting
EICIS := Y.
Ta b l e 5. 5 G l o ba l E n a b l es
Label Prompt
Default
Value
EDCMON Station DC Battery Monitor (N, 1, 2) N
EICIS Independent Control Input Settings (Y, N) N
EDRSTC Data Reset Control (Y, N) N
EGADVS Advanced Global Settings (Y, N) N
EPMU Synchronized Phasor Measurement (Y, N) N
Table 5.6 Station DC1 Monitor (and Station DC2 Monitor)
Label
a
a
Replace 1 with 2 in the setting label.
Prompt
Default
Value
DC1LFP Low Level Fail Pickup (OFF, 15–300 Vdc) 100
DC1LWP Low Level Warn Pickup (OFF, 15–300 Vdc) 127
DC1HWP High Level Warn Pickup (OFF, 15–300 Vdc) 137
DC1HFP High Level Fail Pickup (OFF, 15–300 Vdc) 142
DC1RP Peak to Peak AC Ripple Pickup (1–300 Vac) 9
DC1GF Ground Detection Factor (1.00–2.00) 1.05
Ta b l e 5.7 Co n t ro l I n pu t s
Label Prompt
Default
Value
IN2XXD
a
a
Setting applies to all the Interface Board #1 input contacts.
Int Board #1 Debounce Time (0.0000–5 cyc
b
)
b
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
IN3XXD
c
c
Setting applies to all the Interface Board #2 input contacts.
Int Board #2 Debounce Time (0.0000–5 cyc
b
) 0.1250
Table 5.8 Interface Board #1 Control Inputs
Label Prompt
Default
Value
IN201PU Input IN201 Pickup Delay (0.0000–5 cyc
a
)
a
If the interface board has more than eight input contacts, the upper range is 1 cycle.
0.1250
b
b
Set to Global setting IN2XXD when EICIS := N.
IN201DO Input IN201 Dropout Delay (0.0000–5 cyc
a
)0.1250
b
•
•
•
•
•
•
•
•
•
IN2mmPU
c
c
mm is the number of available input contacts on the interface board.
Input IN2mm
c
Pickup Delay (0.0000–5 cyc
a
)0.1250
b
IN2mmDO
c
Input IN2mm
c
Dropout Delay (0.0000–5 cyc
a
)0.1250
b
