Sel 411L - Table 5.26 Front-Panel Settings

P.5.12
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Front-Panel Settings
Table 5.26 Front-Panel Settings (Sheet 1 of 4)
Label Prompt Default Value
FP_TO Front Panel Display Time-Out
(OFF,1–60 min)
15
EN_LEDC Enable LED Asserted Color (R, G) G
TR_LEDC Trip LED Asserted Color (R, G) R
PB1_LED Pushbutton LED 1 (SEL
OGIC Equation) PLT01 #87L ENABLED
PB1_COL PB1_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB2_LED Pushbutton LED 2 (SEL
OGIC Equation) PLT02 #COMM SCHEME
ENABLED
PB2_COL PB2_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB3_LED Pushbutton LED 3
(SEL
OGIC Equation)
NOT SG1 #ALT SETTINGS
PB3_COL PB3_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB4_LED Pushbutton LED 4 (SEL
OGIC Equation) PLT04 #RELAY TEST
MODE
PB4_COL PB4_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB5_LED Pushbutton LED 5 (SEL
OGIC Equation) NOT E3PT #SPT ENABLED
PB5_COL PB5_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB6_LED Pushbutton LED 6 (SEL
OGIC Equation) PLT06 #MANUAL CLOSE
ENABLED
PB6_COL PB6_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB7_LED Pushbutton LED 7 (SEL
OGIC Equation) PLT07 #RECLOSE
ENABLED
PB7_COL PB7_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB8_LED Pushbutton LED 8 (SEL
OGIC Equation) NA
PB8_COL PB8_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB9_LED
a
Pushbutton LED 9 (SELOGIC Equation) NA
PB9_COL
a
PB9_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB10LED
a
Pushbutton LED 10 (SELOGIC Equation) NA
PB10COL
a
PB10LED Assert and Deassert Color
(Enter 2: R, G, A, O)
AO
PB11LED
a
Pushbutton LED 11 (SELOGIC Equation) 52ACL1 and 52BCL1 and
52CCL1 #BREAKER
CLOSED
PB11COL
a
PB11LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
PB12LED
a
Pushbutton LED 12 (SELOGIC Equation) NOT (52ACL1 and 52BCL1
and 52CCL1) #BREAKER
OPEN
