P.5.13
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Front-Panel Settings
PB12COL
a
PB12LED Assert and Deassert Color
(Enter 2: R, G, A, O)
GO
T1_LED Target LED 1 (SEL
OGIC Equation) (87OP or Z1P or Z1G) and
NOT (SOTFT OR TLED_3)
T1LEDL Target LED 1 Latch (Y, N) Y
T1LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T2_LED Target LED 2
(SEL
OGIC Equation)
(Z2PT OR Z2GT OR Z3PT
OR Z3GT OR Z4PT OR
Z4GT) AND NOT (TLED_1
OR TLED_3 OR TLED_4)
T2LEDL Target LED 2 Latch (Y, N) Y
T2LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T3_LED Target LED 3 (SEL
OGIC Equation) COMPRM AND NOT (Z1P
OR Z1G OR TLED_1 OR
SOTFT)
T3LEDL Target LED 3 Latch (Y, N) Y
T3LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T4_LED Target LED 4 (SEL
OGIC Equation) SOTFT
T4LEDL Target LED 4 Latch (Y, N) Y
T4LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T5_LED Target LED 5 (SEL
OGIC Equation) (Z1P OR Z1G) AND NOT
(TLED_6 OR TLED_7 OR
TLED_8)
T5LEDL Target LED 5 Latch (Y, N) Y
T5LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T6_LED Target LED 6 (SEL
OGIC Equation) (Z2P OR Z2G) AND NOT
(Z1P OR Z1G OR TLED_5
OR TLED_7 OR TLED_8)
T6LEDL Target LED 6 Latch (Y, N) Y
T6LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T7_LED Target LED 7 (SEL
OGIC Equation) (Z3P OR Z3G) AND NOT
(Z1P OR Z2P OR Z1G OR
Z2G OR TLED_5 OR
TLED_6 OR TLED_8)
T7LEDL Target LED 7 Latch (Y, N) Y
T7LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T8_LED Target LED 8 (SEL
OGIC Equation) (Z4P OR Z4G) AND NOT
(Z1P OR Z2P OR Z3P OR
Z1G OR Z2G OR Z3G OR
TLED_5 OR TLED_6 OR
TLED_7)
T8LEDL Target LED 8 Latch (Y, N) Y
Table 5.26 Front-Panel Settings (Sheet 2 of 4)
Label Prompt Default Value
