Sel 411L - Page 532

P.5.14
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Front-Panel Settings
T8LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T9_LED Target LED 9 (SEL
OGIC Equation) PHASE_A OR FTSAG
T9LEDL Target LED 9 Latch (Y, N) Y
T9LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T10_LED Target LED 10 (SEL
OGIC Equation) PHASE_B OR FTSBG
T10LEDL Target LED 10 Latch (Y, N) Y
T10LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T11_LED Target LED 11 (SEL
OGIC Equation) PHASE_C OR FTSCG
T11LEDL Target LED 11 Latch (Y, N) Y
T11LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T12_LED Target LED 12 (SEL
OGIC Equation) GROUND
T12LEDL Target LED 12 Latch (Y, N) Y
T12LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T13_LED Target LED 13 (SEL
OGIC Equation) 87OP
T13LEDL Target LED 13 Latch (Y, N) Y
T13LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T14_LED Target LED 14 (SEL
OGIC Equation) 87LST
T14LEDL Target LED 14 Latch (Y, N) N
T14LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T15_LED Target LED 15 (SEL
OGIC Equation) 87CH1AL or 87CH2AL or
87CH3AL or 87CH1FB or
87CH2FB or 87CH3FB
T15LEDL Target LED 15 Latch (Y, N) N
T15LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T16_LED Target LED 16 (SEL
OGIC Equation) NA
T16LEDL Target LED 16 Latch (Y, N) N
T16LEDC T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T17_LED
b
Target LED 17 (SELOGIC Equation) BK1RS
T17LEDL
b
Target LED 17 Latch (Y, N) N
T17LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T18_LED
b
Target LED 18 (SELOGIC Equation) BK1LO
T18LEDL
b
Target LED 18 Latch (Y, N) N
T18LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T19_LED
b
Target LED 19 (SELOGIC Equation) 79CY1 OR 79CY3
Table 5.26 Front-Panel Settings (Sheet 3 of 4)
Label Prompt Default Value
