P.15.63
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
VECTOR
The VECTOR command displays information useful to the factory for
troubleshooting purposes.
VEC
Use the VEC command to view the exception and diagnostics records in the relay.
VERSION
The VERSION command displays the relay hardware and software
configuration.
VER
Use the VER command to list the part numbers, serial numbers, checksums,
software release numbers, and other important relay configuration information.
When you issue the VER command, the relay displays the latest release
numbers for these items:
➤ FID
➤ CID
➤ Part number
➤ Serial number
➤ SELBOOT BFID
➤ Mainboard memory types and sizes
➤ Front-panel hardware
➤ Analog inputs (W, X, Y, Z) ratings
➤ Interface board inputs and outputs
➤ Extended relay features list
A sample VER command response is shown in Figure 15.7.
=>VER <Enter>
FID=SEL-411L-R101-V0-Z013012-D20101111
CID=B66B
Part Number: 0411L5415XC0X4H343XX22
Serial Number: 2010123234
SELboot:
BFID= SLBT-4XX-R205-V0-Z001002-D20100128
Checksum: A92C
Mainboard:
Code FLASH Size: 12 MB
Data FLASH Size: 52 MB
RAM Size: 32 MB
EEPROM Size: 128 kB
Front Panel: installed
Analog Inputs:
W: Currents: 5 Amp
X: Currents: 5 Amp
Y: Voltage: 67 Volts
Z: Voltage: 67 Volts
Interface Boards:
Board 1: 24 inputs 8 outputs
Board 2: not installed
E4 Configuration: 0
Extended Relay Features:
IEC 61850
If the above information is not as expected, contact SEL for assistance.
=>
Figure 15.7 Sample VER Command Response
Ta b l e 1 5.1 67 VE R C o m m a n d
Command Description Access Level
VER Display the hardware and software configurations. 1, B, P, A, O, 2
