Sel 411L - Table 5.30 Boolean Display Points; Table 5.31 Analog Display Points; Table 5.32 Local Control; Table 5.33 Local Bit SEL OGIC

P.5.17
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Front-Panel Settings
Table 5.30 Boolean Display Points
Label
a
a
Relay Word Bit Name, “Alias,” “Set String,” “Clear String”, “Text Size.”
Prompt
Default
Value
b
b
The relay has no default values programmed for these settings.
[Relay Word
Bit Name]
Name of any element in element store None
[Alias] String of ASCII characters except double quotation marks
c
c
Total length of Boolean Display Point is 20 characters; 19 characters of ASCII string with
1 character reserved for an “=.”
None
[Set String] String of ASCII characters except double quotation marks
c
None
[Clear String] String of ASCII characters except double quotation marks
c
None
[Text Size] S for single, D for double S
Table 5.31 Analog Display Points
Label
a
a
Analog Quantity Name, “User Text and Formatting”, “Text Size.”
Prompt
Default
Value
b
b
The relay has no default values programmed for these settings.
[Analog
Quantity Name]
Name of any element in element store None
[User Text] String of ASCII characters except double quotation
marks and
c
c
Total length of Analog Display Point is 20 characters.
None
[Formatting] Total width characters to right of decimal place, scaling
factor
d
d
See Display Points on page P.7.8 for examples of setting Analog Display Points.
None
[User Text] String of ASCII characters except double quotation
marks and
c
None
[Text Size] S for single, D for double S
Ta b l e 5. 32 L oc a l C o nt r o l
Label
a
a
Local Bit, Local Name, Local Set State, Local Clear State, Pulse Enable.
Prompt
Default
Value
[Local Bit
number]
Valid Local Bit number (LB01, for example) None
[Alias Name] String up to 20 printable ASCII characters except double
quotation marks
None
[Alias
for Set State]
String up to 20 printable ASCII characters except double
quotation marks
None
[Alias for
Clear State]
String up to 20 printable ASCII characters except double
quotation marks
None
[Pulse Enable] Pulse Local Bit (Y, N) N
Ta b l e 5. 33 Lo ca l B it SE L
OGIC
a
a
Settings in Table 5.33 appear if the associated local bit is defined. If no local bits are defined,
the whole category is hidden.
Label Prompt Default Value
LB_SPmm
b
b
mm = 01–32.
Local Bit Supervision (SELOGIC Equation, NA) 1
LB_DPmm
b
Local Bit Status Display (SELOGIC Equation, NA) LBmm
