Date Code 20151029 Protection Manual SEL-411L Relay
SELOGIC Control Equation Programming
SEL-311 and SEL-351 Series Users
Modify your SELOGIC control equations to simulate the process. While you
may be unable to change the state of a discrete input easily, such as IN201,
you can substitute a logical 1 or logical 0 in your logic to simulate the
operation of IN201 and observe the results.
Use the SER capabilities of the relay to monitor and record inputs, internal
calculations, and outputs. For operations that occur very quickly, use the SER
during testing to reconstruct the operation of your logic.
Use the MET PMV and MET AMV commands to display the contents of the
protection or automation math variables.
SEL-311 and SEL-351 Series Users
You can convert logic that you have used in SEL-311 series relays and
SEL-351 series relays to logic for the SEL-400 series. In the SEL-300 series
relays, SEL
OGIC control equation programming is restricted to equations
where the left side value, LVALUE, is fixed. The relay uses primarily free-
form programming. Table 14.28 shows comparable features between the
SEL-311 series relays and the SEL-400 series. Convert programming into
either the free-form style or the fixed style of SEL
OGIC control equations, or
whatever combination you deem appropriate for your application.
Table 14.29 shows the SEL-400 series Boolean operators compared to the
operators used in the SEL-300 series relays.
Table 14.28 SEL-300 Series Relays and SEL-400 Series SELOGIC Control
Equation Programming Features
Feature SEL-311 Series
SEL-400 Series
Protection
Free-Form Style
SELOGIC control equation variables SV1–SV16 PSV01–PSV64
Timer Input SV1–SV16 PCT01–PCT32
Timer Pickup settings SV1PU–SV16PU PCT01PU–PCT32PU
Timer Dropout settings SV1DO–SV16DO PCT01DO–PCT32DO
Timer Outputs SV1T–SV16T PCT01Q–PCT32Q
Latch Bit Set Control SET1–SET16 PLT01S–PLT16S
Latch Bit Reset Control RST1–RST16 PLT01R–PLT16R
Latch Bit LT1–LT16 PLT01–PLT16
Table 14.29 SEL-300 Series Relays and SEL-400 Series SEL
OGIC Control
Equation Boolean Operators
Feature SEL-300 Series SEL-400 Series
Logical AND operator * AND
Logical OR operator + OR
Logical NOT operator ! NOT
Parentheses ( ) ( )
Rising, falling edge operators /, \ R_TRIG, F_TRIG
