Sel 411L - Table 5.16 Time and Date Management

P.5.8
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Global Settings
PHCOMP Frequency Based Phasor Compensation (Y, N) Y
PMSTN
a
Station Name (16 characters) STATION A
PMID PMU Hardware ID (1–65534)
c
1
PHDATAV Phasor Data Set, Voltages (V1, ALL, NA)
d
V1
VYCOMP Voltage Angle Compensation Factor (–179.99 to 180 deg) 0.00
VZCOMP Voltage Angle Compensation Factor (–179.99 to 180 deg) 0.00
PHDATAI Phasor Data Set, Currents (I1, ALL, NA)
e
NA
PHCURR Current Source (IW, IX, S)
f
IW
IWCOMP IW Angle Compensation Factor (–179.99 to 180 deg) 0.00
IXCOMP IX Angle Compensation Factor (–179.99 to 180 deg) 0.00
PHNR
a
Phasor Numerical Representation (I = Integer, F = Floating
Point)
I
PHFMT
a
Phasor Format (R = Rectangular, P = Polar) R
FNR
a
Frequency Numerical Representation (I = Integer,
F = Floating Point)
I
NUMANA
a
Number of Analog Values (0–8) 0
NUMDSW
a
Number of 16-bit Digital Status Words (0, 1, 2) 1
TREA1
a
Trigger Reason Bit 1 (SELOGIC Equation) NA
TREA2
a
Trigger Reason Bit 2 (SELOGIC Equation) NA
TREA3
a
Trigger Reason Bit 3 (SELOGIC Equation) NA
TREA4
a
Trigger Reason Bit 4 (SELOGIC Equation) NA
PMTRIG
a
Trigger (SELOGIC EQUATION)NA
MRTCDLY MaxRTC Synchrophasor Packet Delay (20–1000 ms) 500
RTCRATE Remote Messages per Second
1, 2, 4, 5, 10, 12, 15, 20, 30, 60)
2
a
Setting not available when MFRMT := FM.
b
Option 1 is available only if MRATE = 60.
c
When MFRMT := FM, range is 0–0xFFFFFFFF.
d
When MFRMT := FM, NA setting choice is hidden.
e
When MFRMT := FM, I1 setting choice is hidden, and the ALL setting choice is only available
when PHDATAV := ALL.
f
When MFRMT := FM, BOTH setting choice is hidden.
Table 5.16 Time and Date Management
Label Prompt
Default
Value
DATE_F Date Format (MDY, YMD, DMY) MDY
IRIGC
a
a
If EPMU=Y and MFRMT = C37.118 then force to C37.118 and show only.
IRIG-B Control Bits Definition (None, C37.118) None
UTCOFF Offset From UTC to Local Time (-15.5–15.5) –8
BEG_DST
b
b
hh: Hour of day 0–23
n: Occurrence in month (1–3, L)
d: Day of the week (1–7; Sunday–Saturday)
mm: Month (1–12; Jan–Dec)
Begin DST (hh,n,d,mm or OFF) “2,2,1,3”
END_DST
b
End DST (hh,n,d,mm) “2,1,1,11”
