P.8.24
SEL-411L Relay Protection Manual Date Code 20151029
Oscillography, Events, and SER
Event Reports, Event Summaries, and Event Histories
Figure 8.12 Settings Section of the Event Report
CEVENT
The relay provides a Compressed ASCII event report for SCADA and other
automation applications.
ACSELERATOR QuickSet uses Compressed ASCII
commands to gather event report data. If you want to view the Compressed
ASCII event report data, use a terminal to issue ASCII command CEV. A
sample of the report appears in Figure 8.13; this is a comma-delimited ASCII
file. The relay appends a four-digit hex checksum at the end of the lines in the
Compressed ASCII report.
Items included in the Compressed ASCII event report are similar to the event
report, although the relay reports the items in a special order. CEV files (and
COMTRADE files) include all eight Relay Word bits from each row of the
Relay Word that has at least one element included in the event report digital
elements setting. For the purpose of improving products and services, SEL
sometimes changes the items and item order.
=>>CEV<Enter>
"FID","RID","SID","03E2"
"FID=SEL-411L-1-R101-V0-Z006002-D20130820","Relay 1","Station A","17c0"
"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","0ACA"
8,21,2013,14,4,37,661,"0435"
"EVENT_NUM","EVENT","FLM","TW_LOCATION","Z_BASED_LOCATION","FROM","FREQ","NFREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC",
"SER_NUM","PRIM_VAL","CTR_IA","CTR_IB","CTR_IC","CTR_IG","PTR_VA","PTR_VB","PTR_VC","PTR_VS1","PTR_VS2","CTRW","CTRX","PTRY",
"PTRZ","ERAQ01","ERAQ02","ERAQ03","ERAQ04","ERAQ05","ERAQ06","ERAQ07","ERAQ08","ERAQ09","ERAQ10","ERAQ11","ERAQ12","ERAQ13",
"ERAQ14","ERAQ15","ERAQ16","ERAQ17","ERAQ18","ERAQ19","ERAQ20","GROUP","BREAKER1","HOUR_T1","MIN_T1","SEC_T1","MSEC_T1",
"HOUR_C1","MIN_C1","SEC_C1","MSEC_C1","BREAKER2","HOUR_T2","MIN_T2","SEC_T2","MSEC_T2","HOUR_C2","MIN_C2","SEC_C2","MSEC_C2",
"T_LED1","T_LED2","TARGETS","MB_TRIGGER","MB_TRIP","IA_PF","IA_DEG_PF","IB_PF","IB_DEG_PF","IC_PF","IC_DEG_PF","IG_PF",
"IG_DEG_PF","3I2_PF","3I2_DEG_PF","I1_PF","I1_DEG_PF","VA_PF","VA_DEG_PF","VB_PF","VB_DEG_PF","VC_PF","VC_DEG_PF","VS1_PF",
"VS1_DEG_PF","VS2_PF","VS2_DEG_PF","V1MEM_PF","V1MEM_DEG_PF","V0_PF","V0_DEG_PF","V2_PF","V2_DEG_PF","V1_PF","V1_DEG_PF","IA",
"IA_DEG","IB","IB_DEG","IC","IC_DEG","IG","IG_DEG","3I2","3I2_DEG","I1","I1_DEG","VA","VA_DEG","VB","VB_DEG","VC","VC_DEG",
"VS1","VS1_DEG","VS2","VS2_DEG","V1MEM","V1MEM_DEG","V0","V0_DEG","V2","V2_DEG","V1","V1_DEG","IA_PFD","IA_DEG_PFD","IB_PFD",
"IB_DEG_PFD","IC_PFD","IC_DEG_PFD","IQ_PFD","IQ_DEG_PFD","IG_PFD","IG_DEG_PFD","IA_D","IA_DEG_D","IB_D","IB_DEG_D","IC_D",
"IC_DEG_D","IQ_D","IQ_DEG_D","IG_D","IG_DEG_D","5598"10002,"BG T","TW","94.47(mi)","97.36(ME)","LOCAL",60.00,60,8,8,30.125,
"1131860535","YES",1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0,100,100,1000.0,1000.0," "," "," "," "," "," "," "," "," "," "," "," ","
"," "," "," "," "," "," "," ",1,"CLOSED",21,4,37,661, , , , ,"CLOSED",21,4,37,661, , , , ,22688,8,"INST COMM B_PHASE GND 87L
Remote Analog Outputs
RAO01 := NA
RAO02 := NA
RAO61 := NA
RAO62 := NA
RAO63 := NA
RAO64 := NA
Mirrored Bits Transmit Equations
TMB1A := NA
TMB8B := NA
Protection 1
Freeform Protection SELogic
1: ### PROTECTION FREEFORM AUTOMATION EXAMPLE
2: ###
3: ### SET CONTROL VARIABLE 1
4: ### ASSERTS WHEN PRIMARY POSITIVE SEQUENCE IS
5: ### GREATER THAN 90% OF 230 KV DIVIDED BY SQRT 3
6: PSV01 : V1M > 119.5 #90% OF 230 KV DIVIDED BY SQRT 3
Alias
Relay Aliases
(Relay Word Bit or Analog Quantity name, 7 Character Alias [0-9 A-Z _])
1: EN,"REL_EN"
Active Protection Logic Settings
•
•
•
Remote Analog Settings
MIRRORED BITS Settings
Alias Settings
