Sel 411L - Table 5.27 Selectable Screens for the Front Panel

P.5.15
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Front-Panel Settings
T19LEDL
b
Target LED 19 Latch (Y, N) N
T19LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T20_LED
b
Target LED 20 (SELOGIC Equation) 25A1BK1
T20LEDL
b
Target LED 20 Latch (Y, N) N
T20LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T21_LED
b
Target LED 21 (SELOGIC Equation) 50P1 OR 50P2 OR 50P3 OR
50P4 OR 50Q1 OR 50Q2 OR
50Q3 OR 50Q4 OR 50G1
OR 50G2 OR 50G3 OR
50G4
T21LEDL
b
Target LED 21 Latch (Y, N) Y
T21LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T22_LED
b
Target LED 22 (SELOGIC Equation) 51T01 OR 51T02 OR 51T03
OR 51T04 OR 51T05 OR
51T06 OR 51T07 OR 51T08
OR 51T09 OR 51T10
T22LEDL
b
Target LED 22 Latch (Y, N) Y
T22LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T23_LED
b
Target LED 23 (SELOGIC Equation) LOP
T23LEDL
b
Target LED 23 Latch (Y, N) N
T23LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
T24_LED
b
Target LED 24 (SELOGIC Equation) TIRIG
T24LEDL
b
Target LED 24 Latch (Y, N) N
T24LEDC
b
T_LED Assert and Deassert Color
(Enter 2: R, G, A, O)
RO
a
PB9–PB12 settings are only available on 12 pushbutton models.
b
T17–T24 settings are only available on 12 pushbutton models.
Table 5.27 Selectable Screens for the Front Panel (Sheet 1 of 2)
Label Prompt Default Value
SCROLD Front-Panel Display Update Rate (OFF, 1–15 sec-
onds)
a
5
ONELINE One-Line Bay Control Diagram (Y, N) N
RMS_V RMS Line Voltage Screen (Y, N) N
RMS_I RMS Line Current Screen (Y, N) Y
RMS_VPP RMS Line Voltage Phase to Phase Screen (Y, N) N
RMS_W RMS Active Power Screen (Y, N) N
FUNDVAR Fundamental Reactive Power Screen (Y, N) N
RMS_VA RMS Apparent Power Screen (Y, N) N
RMS_PF RMS Power Factor Screen (Y, N) N
RMS_BK1 RMS Breaker 1 Currents Screen (Y, N) N
Table 5.26 Front-Panel Settings (Sheet 4 of 4)
Label Prompt Default Value
