Sel 411L - Table 15.161 TEST FM off Command; Table 15.162 TEST FM PEAK Command; Table 15.163 TIME Command

P.15.61
Date Code 20151029 Protection Manual SEL-411L Relay
ASCII Command Reference
Description of Commands
TEST FM OFF
Use the TEST FM OFF command to remove override values. The relay
returns the Fast Meter registers to the pretest values.
When you have successfully removed a Fast Meter test value (for example,
TEST FM IA1 OFF), the relay responds,
Override Removed. When an
attempt to remove an FM test value fails, the relay responds,
Override Not
Found
. When removing all FM test values (for example, TEST FM OFF), the
relay responds,
All Overrides Removed.
TEST FM PEAK
Use the TEST FM PEAK command to insert override values in Fast Meter
peak demand metering.
TIME
Use the TIME command to view and set the relay time clock. The ASCII
interface is just one source by which you can set the internal clock. Other
sources can override the ASCII TIME command; overriding occurs in HIRIG
time mode, IRIG time mode, and when using DNP. See Configuring High-
Accuracy Timekeeping on page P.13.1 for more information on configuring
time functions.
TIME
The TIME command returns information about the internal relay clock. You
can also set the clock to local time if you specify hours and minutes (seconds
data are optional). Separate the hours, minutes, and seconds with colons,
semicolons, spaces, commas, or slashes.
=>>TIME<Enter>
local: 16:48:33 UTC: 23:48:33 UTC Offset: -07.0 hrs
If a valid IRIG-B or SNTP signal is connected to the relay, the TIM command
cannot be used to set the relay time.
Table 15.161 TEST FM OFF Command
Command Description Access Level
TEST FM label
OFF
Clear the override values for the Fast Meter item label. B, P, A, O, 2
TEST FM OFF Clear all override testing values from Fast Meter. B, P, A, O, 2
Table 15.162 TEST FM PEAK Command
Command Description Access Level
TEST FM PEAK
label value1
Write new data value1 to the Fast Meter peak
demand meter report at the item label label.
B, P, A, O, 2
Ta b l e 1 5.1 6 3 T I M E C om m a nd
Command Description Access Level
TIME Display the present relay internal clock time,
in three formats: local, UTC, and UTC offset.
1, B, P, A, O, 2
TIME hh:mm Set the relay internal clock to hh:mm. 1, B, P, A, O, 2
TIME hh:mm:ss Set the relay internal clock to hh:mm:ss. 1, B, P, A, O, 2
