P.5.18
SEL-411L Relay Protection Manual Date Code 20151029
Settings
Port Settings
Port Settings
Table 5.34 SER Parameters
Label Prompt Default Value
SER_PP 5 Events per SER Events page ? (Y for 5, N for 3) N
Table 5.35 Port Settings Categories
Settings Reference
Protocol Selection See Table 5.36.
Communications Settings See Table 5.37.
SEL Protocol Settings See Table 5.38.
Fast Message Read Data Access See Table 5.39.
DNP3 Serial Protocol Settings See Table 5.40.
DNP3 LAN/WAN Settings See Table 5.41.
M
IRRORED BITS Protocol Settings See Table 5.42.
RTD Protocol Settings See Table 5.43.
PMU Protocol Settings See Table 5.44.
87L Port Settings See Table 5.45.
87L Channel Monitoring Settings See Table 5.46.
87L Communications Bits Debounce Time Delay—
Serial Communication
See Table 5.47.
87L Communications Bits Debounce Time Delay—
Ethernet Communication
See Table 5.48.
Ethernet Settings See Ethernet Network Opera-
tion Settings on page C.1.5.
FTP Settings See FTP on page C.1.11.
Telnet Settings See Telnet on page C.1.12.
IEC 61850 Settings See Section 5: IEC 61850
Communications in the Com-
munications Manual.
SNTP Settings See Configuring SNTP Client
in the Relay on page C.2.20.
Table 5.36 Protocol Selection
Label Prompt Default Value
EPORT Enable Port (Y, N) Y
MAXACC
a
a
Not available on the front port.
Maximum Access Level (1, B, P, A, 0, 2, C) C
PROTO Protocol (SEL, DNP, MBA, MBB, MBGA, MBGB,
RTD, PMU)
SEL
