P.6.2
SEL-411L Relay Protection Manual Date Code 20151029
PC Software
Overview
Obtaining
ACSELERATOR QuickSet
ACSELERATOR QuickSet can be obtained from the Download area of the SEL
website. In order to have the software automatically update as new relay
drivers are released, download and install SEL Compass Software, then use
Compass to download and install
ACSELERATOR QuickSet. When you
download
ACSELERATOR QuickSet within Compass, you will be asked to
select which relay drivers you wish to include. Select drivers for all SEL
relays that you may be required to set. If later you find that additional drivers
are required,
ACSELERATOR QuickSet provides an easy method to request
new drivers and updates (see Updating
ACSELERATOR QuickSet).
ACSELERATOR QuickSet is also available on CD upon request.
ACSELERATOR QuickSet
Main Menu
The main menu provides the following options and submenu options. Selected
submenu options are explained in detail in Table 6.3.
Ta b l e 6 . 2 ACSELERATOR QuickSet Applications
Application Description
Terminal Provides a direct connection to the SEL device. Use this feature to ensure proper communications
and directly interface with the device.
HMI Provides a summary view of device operation. Use this feature to simplify commissioning testing.
Rules Based Settings Editor Provides on-line or off-line device settings that include interdependency checks. Use this feature
to create and manage settings for multiple devices in a database.
Event Analysis Provides oscillography and other event analysis tools.
Settings Database Management
ACSELERATOR QuickSet uses a database to manage the settings of multiple devices.
Help Provides general
ACSELERATOR QuickSet and device specific ACSELERATOR QuickSet context
sensitive help.
Ta b l e 6 . 3 ACSELERATOR QuickSet Submenu Options (Sheet 1 of 2)
File
➤ New—Create new settings for a connected device or offline
➤ Open—Open existing settings stored in a Relay Database (RDB) file
➤ Close—Close settings instance that is open in the ACSELERATOR QuickSet window
➤ Save/Save As—Save settings instance that is open in the ACSELERATOR QuickSet window to the active
Relay Database (RDB) file
➤ Print Device Settings—Print standard or custom settings reports
➤ Read—Read settings from a connected device and display the settings in the ACSELERATOR QuickSet
window
➤ Send—Send settings instance that is open in the ACSELERATOR QuickSet window to a connected device
➤ Active Database—Change which Relay Database (RDB) file is used for the Open and Save/Save As com-
mands.
➤ Database Manager—Open Database Manager to create a new Relay Database (RDB) file, copy settings
within the active Relay Database (RDB) file, add descriptions to settings within the database, and copy and
move settings between different databases.
➤ Exit—Quit the ACSELERATOR QuickSet software
Edit
➤ Copy—Copy settings from one Settings Group to another
➤ Search—Search for a text string within the settings instance
➤ Compare—Compare the settings instance that is open in the ACSELERATOR QuickSet window to another
settings instance in the Relay Database file
➤ Merge—Merge the settings instance that is open in the ACSELERATOR QuickSet window with another
settings instance in the Relay Database file
➤ Part Number—Change the current part number for the settings instance that is open in the ACSELERATOR
QuickSet window
