SEL-411L Relay Protection Manual Date Code 20151029
ASCII Command Reference
Description of Commands
An example response to the GOOSE commands is shown in Figure 15.2.
=>>GOOSE <Enter>
GOOSE Transmit Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_411L_OtterCFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-10 4:1 1 166 457
Data Set: SEL_411L_OtterCFG/LLN0$DSet13
GOOSE Receive Status
MultiCastAddr Ptag:Vlan StNum SqNum TTL Code
-----------------------------------------------------------------------------
SEL_411L_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-04 : 0 0 0 TTL EXPIRED
Data Set: SEL_487B_1CFG/LLN0$DSet13
SEL_2440_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-0A : 0 0 0 TTL EXPIRED
Data Set: SEL_2440_1CFG/LLN0$DSet13
SEL_487E_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-10 : 0 0 0 TTL EXPIRED
Data Set: SEL_487E_1CFG/LLN0$DSet13
SEL_710_1CFG/LLN0$GO$GooseDSet13
01-0C-CD-01-00-08 : 0 0 0 TTL EXPIRED
Data Set: SEL_710_1CFG/LLN0$DSet13
Figure 15.2 GOOSE Command Response
If the GOOSE command is issued during CID file processing, the relay
responds with
CID file is currently being processed. No GOOSE
statistics available
. When GOOSE is disabled by settings (EGSE = N),
the relay sends
Command is not available in responding to a GOOSE
command. If an error is detected during the processing of the IEC 61850 file,
the relay responds
Error detected in parsing the CID file. All GOOSE
processing disabled
to a GOOSE command.
GROUP
Use the GROUP command to view the present group number or to change the
active group.
When you change the active group, the relay responds with a confirmation
prompt:
Are you sure (Y/N)? Answer Y <Enter> to change the active
group. The relay asserts the Relay Word bit SALARM for one second when
you change the active group.
If any of the SEL
OGIC control equations SS1–SS6 are set when you issue the
GROUP n command, the group change will fail. The relay responds
No
group change: SELogic equations SS1-SS6 have priority over GROUP
command
.
HELP
The HELP command gives a list of commands available at the present access
level. You can also get a description of any particular command; type HELP
followed by the name of the command for help on each command.
Ta b l e 1 5.70 G R O U P C o m m a n d
Command
a
a
Parameter n indicates group numbers 1–6.
Description Access Level
GROUP Display the presently active group. 1, B, P, A, O, 2
GROUP n Change the active group to Group n. B, P, A, O, 2
