Sel 411L - Table 5.41 DNP3 LAN;WAN Settings

P.5.21
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Port Settings
Make Table 5.41 settings if configuring DNP3 LAN/WAN.
–
Make Table 5.42 settings if Port setting PROTO := MBA or MBB.
Table 5.41 DNP3 LAN/WAN Settings
Label Prompt Default Value
EDNP Enable DNP3 sessions (0–6) 0
DNPADR DNP3 Address (0–65519) 0
DNPPNUM DNP3 TCP and UDP Port (1025–65534) 20000
DNPID DNP3 ID for Object 0, Var 246 (20 characters) “RELAY1-DNP”
Ethernet DNP3 Master [n] Configuration, n=1 to value of EDNP, max 6
a
DNPIPn IP Address (w.x.y.z) 192.168.1.[100+n]
DNPTRn Transport Protocol (UDP, TCP) TCP
DNPUDPn
b,c
UDP Response Port (REQ, 1025–65534) 20000
DNPMAPn DNP3 Session Map (1–5) 1
CLASSBn Class for Binary Event Data (OFF,1–3) 1
CLASSCn Class for Counter Event Data (OFF,1–3) OFF
CLASSAn Class for Analog Event Data (OFF,1–3) 2
TIMERQn Time-Set Request Interval (I,M,1–32767 mins) I
DECPLAn Currents Scaling (0–3 decimal places) 1
DECPLVn Voltages Scaling (0–3 decimal places) 1
DECPLMn Misc Data Scaling (0–3 decimal places) 1
STIMEOn Select/Operate Time-Out (0–60 s) 1
DNPINAn
d
Seconds to Send Data Link Heartbeat (0–7200) 120
DNPCLn Enable Control Operations (Y,N) N
AIVARn Default Variation for Analog Inputs (1–6) 2
ANADBAn
e
Analog Reporting Deadband for Currents (0–32767) 100
ANADBVn
e
Analog Reporting Deadband for Voltages (0–32767) 100
ANADBMn
e
Analog Reporting Deadband (0–32767) 100
ETIMEOn Event Message Confirm Time-Out (1–50 s) 2
UNSOLn
f
Enable Unsolicited Reporting (Y,N) N
PUNSOLn
g
Enable Unsolicited Reporting at Power-Up (Y,N) N
REPADRn
g
DNP3 Address (0–65519) 1
NUMEVEn
g
Number of Events to Transmit On (1–200) 10
AGEEVEn
g
Age of Oldest Event to Transmit On (0–99999) 2
URETRYn
g
Unsolicited Message Max Retry Attempts (2–10) 3
UTIMEOn
g
Unsol. Message Offline Time-Out (1–5000 s) 60
a
Hidden if EDNP := 0.
b
Hidden if DNPTRn := TCP.
c
Must be unique for all active UDP settings (DNPUDP1–6, PMOUDP1–2).
d
Hidden if DNPTRn := UDP.
e
Hidden if CLASSAn := OFF.
f
Hidden if CLASSAn := CLASSBn := CLASSCn := OFF.
g
Hidden if UNSOLn := N.
