P.5.27
Date Code 20151029 Protection Manual SEL-411L Relay
Settings
Bay Settings
52yCLSM Breaker y Close Status (SELOGIC Equation) 52ACLy
523CLSM = NA
52y_ALM Breaker y Alarm Status (SEL
OGIC Equation) 52AALy
523_ALM = NA
DrHMIN
d
Disconnect m HMI Name (max 17 pixels, 3–4 characters)
e
SW[m]
DrCTLN Disconnect m Control Scr. Name (max 15 char.) BB [m]
89AMr Disconnect m N/O Contact (SELOGIC Equation) 1
89BMr Disconnect m N/C Contact (SEL
OGIC Equation) 0
89ALPr Disconnect m Alarm Pickup Delay (1–99999 cyc) 300
89CCNr Dis. m Remote Close Control (SEL
OGIC Equation) 89CCr
89OCNr Dis. m Remote Open Control (SEL
OGIC Equation) 89OCr
89CSTr Dis. m Close Seal-in Time (OFF, 1–99999 cyc) 280
89CITr Dis. m Close Immobility Time (OFF, 1–99999 cyc) 20
89CRSr Disconnect m Close Reset (SEL
OGIC Equation) 89CLr OR 89CSIr
89CBLr Disconnect [m] Close Block (SEL
OGIC Equation) NA
89OSTr Dis. m Open Seal-in Time (OFF, 1–99999 cyc) 280
89OITr Dis. m Open Immobility Time (OFF, 1–99999 cyc) 20
89ORSr Disconnect m Open Reset (SEL
OGIC Equation) 89OPNr OR 89OSIr
89OBLr Disconnect m Open Block (SEL
OGIC Equation) NA
89CIRr Dis. m Close Immob. Time Reset (SEL
OGIC Equation) NOT 89OPNr
89OIRr Dis. m Open Immob. Time Reset (SEL
OGIC Equation) NOT 89CLr
MDELEn
f
Analog Quantity <Blank>
MDNAMx Pre-text <Blank>
MDSETx Text Formatting {w.d} <Blank>
MDCLRx Post-text
MDSCAx Scale Format {s} 1
LOCAL Local Control (SEL
OGIC Equation) NA
a
x = 1—9.
b
y = 1—3.
c
z = 1—2.
d
r = 01—10.
e
m = 1—10.
f
n = 1—24.
Table 5.57 Bay Settings (Sheet 2 of 2)
Label Prompt Default Value
