P.17.29
Date Code 20151029 Protection Manual SEL-411L Relay
Analog Quantities
Quantities Listed by Function
V1YPMAD Positive-sequence synchrophasor voltage angle, Terminal Y, delayed
for RTC alignment
Degrees [°] (±180°)
V1ZPMAD Positive-sequence synchrophasor voltage angle, Terminal Z, delayed
for RTC alignment
Degrees [°] (±180°)
V1YPMRD Positive-sequence synchrophasor voltage real component, Terminal Y,
delayed for RTC alignment
Kilo Volts [kV] (primary)
V1ZPMRD Positive-sequence synchrophasor voltage real component, Terminal Z,
delayed for RTC alignment
Kilo Volts [kV] (primary)
V1YPMID Positive-sequence synchrophasor voltage imaginary component,
Terminal Y, delayed for RTC alignment
Kilo Volts [kV] (primary)
V1ZPMID Positive-sequence synchrophasor voltage imaginary component,
Terminal Z, delayed for RTC alignment
Kilo Volts [kV] (primary)
IAWPMMD, IBWPMMD,
ICWPMMD
Synchrophasor current magnitude, A-phase, B-phase, C-phase,
Terminal W, delayed for RTC alignment
Amperes [A] (primary)
IAXPMMD, IBXPMMD,
ICXPMMD
Synchrophasor current magnitude, A-phase, B-phase, C-phase,
Terminal X, delayed for RTC alignment
Amperes [A] (primary)
IASPMMD, IBSPMMD,
ICSPMMD
Synchrophasor current magnitude, A-phase, B-phase, C-phase,
Terminal S, delayed for RTC alignment
Amperes [A] (primary)
IAWPMAD, IBWPMAD,
ICWPMAD
Synchrophasor current angle, A-phase, B-phase, C-phase,
Terminal W, delayed for RTC alignment
Degrees [°] (±180°)
IAXPMAD, IBXPMAD,
ICXPMAD
Synchrophasor current angle, A-phase, B-phase, C-phase, Terminal X,
delayed for RTC alignment
Degrees [°] (±180°)
IASPMAD, IBSPMAD,
ICSPMAD
Synchrophasor current angle, A-phase, B-phase, C-phase, Terminal S,
delayed for RTC alignment
Degrees [°] (±180°)
IAWPMRD, IBWPMRD,
ICWPMRD
Synchrophasor current real component, A-phase, B-phase, C-phase,
Terminal W, delayed for RTC alignment
Amperes [A] (primary)
IAXPMRD, IBXPMRD,
ICXPMRD
Synchrophasor current real component, A-phase, B-phase, C-phase,
Terminal X, delayed for RTC alignment
Amperes [A] (primary)
IASPMRD, IBSPMRD,
ICSPMRD
Synchrophasor current real component, A-phase, B-phase, C-phase,
Terminal S, delayed for RTC alignment
Amperes [A] (primary)
IAWPMID, IBWPMID,
ICWPMID
Synchrophasor current imaginary component, A-phase, B-phase,
C-phase, Terminal W, delayed for RTC alignment
Amperes [A] (primary)
IAXPMID, IBXPMID,
ICXPMID
Synchrophasor current imaginary component, A-phase, B-phase,
C-phase, Terminal X, delayed for RTC alignment
Amperes [A] (primary)
IASPMID, IBSPMID,
ICSPMID
Synchrophasor current imaginary component, A-phase, B-phase,
C-phase, Terminal W, delayed for RTC alignment
Amperes [A] (primary)
I1WPMMD Positive-sequence synchrophasor current magnitude, Terminal W,
delayed for RTC alignment
Amperes [A] (primary)
I1XPMMD Positive-sequence synchrophasor current magnitude, Terminal X,
delayed for RTC alignment
Amperes [A] (primary)
I1SPMMD Positive-sequence synchrophasor current magnitude, Terminal S,
delayed for RTC alignment
Amperes [A] (primary)
I1WPMAD Positive-sequence synchrophasor current angle, Terminal W, delayed
for RTC alignment
Degrees [°] (±180°)
I1XPMAD Positive-sequence synchrophasor current angle, Terminal X, delayed
for RTC alignment
Degrees [°] (±180°)
I1SPMAD Positive-sequence synchrophasor current angle, Terminal S, delayed
for RTC alignment
Degrees [°] (±180°)
I1WPMRD Positive-sequence synchrophasor current real component,
Terminal W, delayed for RTC alignment
Amperes [A] (primary)
Table 17.2 Analog Quantities List By Function (Sheet 11 of 15)
Analog Quantities Analog Quantity Description Units
