Analog Quantities
Quantities Listed by Function
DI0X Terminal X zero-sequence (I0) current phasor 1-cycle difference,
magnitude
Per unit [pu]
DVA1Y Terminal Y positive-sequence (V1) voltage phasor 1-cycle
difference, magnitude
Per unit [pu]
DVA2Y Terminal Y negative-sequence (V2) voltage phasor 1-cycle
difference, magnitude
Per unit [pu]
DV0Y Terminal Y zero-sequence (V0) voltage phasor 1-cycle difference,
magnitude
Per unit [pu]
DVA1Z Terminal Z positive-sequence (V1) voltage phasor 1-cycle
difference, magnitude
Per unit [pu]
DVA2Z Terminal Z negative-sequence (V2) voltage phasor 1-cycle
difference, magnitude
Per unit [pu]
DV0Z Terminal Z zero-sequence (V0) voltage phasor 1-cycle difference,
magnitude
Per unit [pu]
DI11R, DI12R, DI13R Remote Terminal 1, Terminal 2, Terminal 3 positive-sequence (I1)
current phasor 1-cycle difference, magnitude
Per unit [pu]
DIQ1R, DIQ2R, DIQ3R Remote Terminal 1, Terminal 2, Terminal 3,negative-sequence (3I2)
current phasor 1-cycle difference, magnitude
Per unit [pu]
DIG1R, DIG2R, DIG3R Remote Terminal 1, Terminal 2, Terminal 3 zero-sequence (3I0)
current phasor 1-cycle difference, magnitude
Per unit [pu]
Table 17.2 Analog Quantities List By Function (Sheet 15 of 15)
Analog Quantities Analog Quantity Description Units
