P.A.4
SEL-411L Relay Protection Manual Date Code 20151029
Firmware and Manual Versions
Firmware
➤ Made all of the INxxx and OUTxxx Relay Word bits visible
regardless of hardware configuration.
➤ Revised the firmware to display the alias Relay Word bits names
instead of "Unused" in the COMTRADE .cfg file.
➤ Changed the 81UVSP default setting from 56 V to 85 V.
➤ Added third pass-band filter to synchrophasor filter selections.
➤ Added Traveling Wave peak arrival times to DNP map and IEC
61850.
➤ Enhanced synchrophasor digital and analog mapping.
➤ Added phase-phase current-only fault identification Relay Word
bits.
➤ Increased number of binary outputs to 100 in custom DNP map.
➤ Implemented multiple updates to the DNP3 control point
operations.
➤ Made frequency elements immune to TRIP condition.
SEL-411L-R116-V0-Z008002-D20141224
SEL-411L-1-R116-V0-Z008002-D20141224
➤ Manual Update only (see Table A.5) 20150126
SEL-411L-R116-V0-Z008002-D20141224
SEL-411L-1-R116-V0-Z008002-D20141224
➤ Added support of 87L line current differential protection using
Ethernet communications.
➤ Added DNP reference FFROM to indicate the fault location
reference terminal.
➤ Enhanced G.703 protocol to either produce its own clock signal
or recover an external clock signal to synchronize its transmit
rate. Setting 87TIMC was added to control this behavior.
20141224
SEL-411L-R115-V0-Z007002-D20140912
SEL-411L-1-R115-V0-Z007002-D20140912
➤ Changed the 87L blocking function to include group setting
E87L = N. This prevents inadvertent operation of the
differential element when E87L is changed to N at one terminal.
➤ Improved 87L channel synchronization to prevent misalignment
on C37.94 and EIA-422 serial cards that have not been
synchronized to a multiplexer which provides a correct external
clock signal.
➤ Improved warm start initialization to prevent inadvertent
operation of the differential element during a settings change or
group switch while load currents are applied.
20140912
SEL-411L-R114-V0-Z007002-D20140429
SEL-411L-1-R114-V0-Z007002-D20140429
Note: Firmware versions R112 and R113 did
not production release.
➤ Added setting EFID to enable/disable Fault Identification Logic.
➤ Added setting EWDSEC to enable/disable the 87L Watchdog
counters for testing purposes.
➤ Modified how 10-cycle analog quantities are initialized.
➤ Added MIRRORED BITS Group Protocol Setting (MBG).
➤ Improved 87L channel delay calculation to reduce channel
alarms when the channel delay is constantly changing.
➤ Changed the 87L time fallback modes to ensure proper fallback
to channel-based synchronization mode in the presence of
intermittent IRIG signals.
➤ Changed the 87L time fallback modes to ensure proper fallback
and operation during a settings change. In previous firmware,
the relay could lose channel synchronization with other relays
when it was set to time-based synchronization (87CHnSN = T)
and while it was in time fallback to channel-based
synchronization mode and a setting change occurred.
20140429
Table A.1 Firmware Revision History (Sheet 3 of 6)
Firmware Identification (FID) Number Summary of Revisions
Manual
Date Code
