Date Code 20151029 Protection Manual SEL-411L Relay
Protection Functions
87L Communications Report
FID=(a)
Statistics previously cleared on mm/dd/yyyy hh:mm:ss.sss (UTC)
87L APPLICATION STATUS
(f)
(i)
(j)
MEDIUM/PROTOCOL Configuration Status
Serial Channel 1 (p) (q)
Serial Channel 2 (p) (q)
Ethernet Port A (p) (d)
Ethernet Port B (p) (d)
Synchronization (k) (l)
Time Fallback (n) (n)
TIME SOURCE Local Status Remote Status
(m) (m)
CHANNEL ADDRESSING
Local Address (g,h)
Remote Address 1 (g,h)
Remote Address 2 (g,h)
Remote Address 3 (h)
VLAN Tag (c)
STATISTICS Channel 1 Channel 2 Channel 3
Channel Status (o) (o) (o)
Channel Role (s) (s) (s)
2SD Role / 24 hr Usage (t,oo) (t,oo)
Receive Status (u) (u) (u)
Synch Config (w) (w) (w)
Synch Status (w) (w) (w)
Synch Accuracy (x) (x) (x)
Time Status (r) (r) (r)
High Lost Packet Count (v) (v) (v)
High Latency (y) (y)
High Asymmetry (z) (z)
Round-Trip Delay (ms) (aa) (aa)
Transmit Delay (ms) (bb) (bb)
Receive Delay (ms) (cc) (cc) (cc)
Asymmetry (ms) (dd) (dd)
Lost Packet Count 40s (ee) (ee) (ee)
Lost Packet Count 24hr (ff) (ff) (ff)
MAXIMUM VALUES
Channel 1 Date and Time (UTC)
Lost Packet Count 24hr (gg) mm/dd/yyyy hh:mm:ss
Round-Trip Delay (ms) (jj) mm/dd/yyyy hh:mm:ss.sss
Transmit Delay (ms) (kk) mm/dd/yyyy hh:mm:ss.sss
Receive Delay (ms) (ll) mm/dd/yyyy hh:mm:ss.sss
Asymmetry (ms) (nn) mm/dd/yyyy hh:mm:ss.sss
Channel 2 Date and Time (UTC)
Lost Packet Count 24hr (gg) mm/dd/yyyy hh:mm:ss
Round-Trip Delay (ms) (jj) mm/dd/yyyy hh:mm:ss.sss
Transmit Delay (ms) (kk) mm/dd/yyyy hh:mm:ss.sss
Receive Delay (ms) (ll) mm/dd/yyyy hh:mm:ss.sss
Asymmetry (ms) (nn) mm/dd/yyyy hh:mm:ss.sss
Channel 3 Date and Time (UTC)
Lost Packet Count 24hr (gg) mm/dd/yyyy hh:mm:ss
Receive Delay (ms) (ll) mm/dd/yyyy hh:mm:ss.sss
HISTOGRAMS
Channel Receive Delay (last 24 hours)
Delay (ms) Channel 1 (%) Channel 2 (%) Channel 3 (%)
0 - 2 (pp) (pp) (pp)
2 - 4 (pp) (pp) (pp)
4 - 6 (pp) (pp) (pp)
6 - 8 (pp) (pp) (pp)
8 - 10 (pp) (pp) (pp)
10 - 12 (pp) (pp) (pp)
12 - 15 (pp) (pp) (pp)
15 - 20 (pp) (pp) (pp)
20 - 30 (pp) (pp) (pp)
30+ (pp) (pp) (pp)
Channel Round-Trip Delay (last 24 hours)
Delay (ms) Channel 1 (%) Channel 2 (%)
0 - 2 (ii) (ii)
2 - 4 (ii) (ii)
4 - 6 (ii) (ii)
6 - 8 (ii) (ii)
8 - 10 (ii) (ii)
10 - 12 (ii) (ii)
12 - 15 (ii) (ii)
