Sel 411L - Page 500

P.4.46
SEL-411L Relay Protection Manual Date Code 20151029
Autoreclosing and Synchronism-Check
Settings and Relay Word Bits for Autoreclosing and Manual Closing
ULCL1 Unlatch Closing for Breaker 1(SELOGIC Equation) 52AA1 AND
52AB1 AND
52AC1
ULCL2 Unlatch Closing for Breaker 2 (SEL
OGIC Equation) 52AA2 AND
52AB2 AND
52AC2
79DTL Recloser Drive to Lockout (SEL
OGIC Equation) NA
79BRCT Block Reclaim Timer (SEL
OGIC Equation) NA
BK1MCL Breaker 1 Manual Close (SEL
OGIC Equation) (CC1 OR
PB11PUL)
AND PLT06
BK2MCL Breaker 2 Manual Close (SEL
OGIC Equation) NA
3PMRCD Manual Close Reclaim Time Delay (1–99999 cycles) 900
BK1CLSD BK1 Reclose Supervision Delay (OFF, 1–99999 cycles) 7200
BK2CLSD BK2 Reclose Supervision Delay (OFF, 1–99999 cycles) 7200
Single-Pole Reclose
SPOISC Single-Pole Open Interval Supervision
(SEL
OGIC Equation)
b
1
SPOISD Single-Pole Open Interval Supervision Delay
(OFF, 1–99999 cycles)
1
SPOID Single-Pole Open Interval Delay (1–99999 cycles) 60
SPRCD Single-Pole Reclaim Time Delay (1–99999 cycles) 900
SPRI Single-Pole Reclose Initiation (SEL
OGIC Equation) SPT
SP1CLS Single-Pole BK1 Reclose Supervision
(SEL
OGIC Equation)
b
1
SP2CLS Single-Pole BK2 Reclose Supervision
(SEL
OGIC Equation)
b
1
Three-Pole Reclose
3POISC Three-Pole Open Interval Supervision
(SELOGIC Equation)
b
1
3POISD Three-Pole Open Interval Supervision Delay
(OFF, 1–99999 cycles)
1
3POID1 Three-Pole Open Interval 1 Delay (1–99999 cycles) 180
3POID2 Three-Pole Open Interval 2 Delay (1–99999 cycles) 180
3POID3 Three-Pole Open Interval 3 Delay (1–99999 cycles) 180
3POID4 Three-Pole Open Interval 4 Delay (1–99999 cycles) 180
3PFARC Three-Pole Fast Automatic Reclose Enable
(SEL
OGIC Equation)
NA
3PFOID Three-Pole Fast Open Interval Delay (1–99999 cycles) 60
3PRCD Three-Pole Reclaim Time Delay (1–99999 cycles) 900
3PRI Three-Pole Reclose Initiation (SEL
OGIC Equation) 3PT AND NOT
(Z2PT OR Z2GT
OR Z3PT OR
Z3GT OR
SOTFT)
3PRIH Three-Pole Reclose Open Failure Delay (OFF, 1–99999) 15
79SKP Skip Reclosing Shot (SEL
OGIC Equation) NA
Table 4.24 Autoreclose Logic Settings
a
(Sheet 2 of 3)
Label Prompt Default Value
