P.1.12
SEL-411L Relay Protection Manual Date Code 20151029
Introduction and Specifications
Applications
Communications
capability
SEL ASCII
Enhanced M
IRRORED BITS communications
SEL Fast Meter, SEL Fast Operate, SEL Fast SER
SEL Compressed ASCII
Phasor Measurement Unit (PMU) protocols
RTD
Optional Serial DNP3
Optional protocols: Ethernet, IEC 61850, DNP3 (Ethernet),
FTP, Telnet
Customized protection
and automation schemes
Separate protection and automation SEL
OGIC control
equation programming areas
Use timers and counters in expanded SEL
OGIC control
equations for complete flexibility
Synchrophasors The relay can function as a phasor measurement unit (PMU) at
the same time as it provides best-in-class protective relay
functions.
C37.118 message format allows up to eight current and eight
voltage synchronized measurements, up to 60 messages per
second (on a 60 Hz nominal power system). Two choices of
filter response, settable angle correction, and choice of
numeric representation makes the data usable for a variety of
synchrophasor applications.
SEL Fast Operate commands are available on the synchropha-
sor communications ports, allowing control actions initiated
by the synchrophasor processor.
SEL Fast Message Synchrophasor format is also available,
with up to four current and four voltage synchronized mea-
surements.
Table 1.2 Application Highlights (Sheet 3 of 3)
Application Key Features
