ACSELERATOR QuickSet HMI
The flashing LED representation in the lower left of the ACSELERATOR
QuickSet window indicates an active data update via the communications
channel (see Figure 6.3). Click the button marked Disable Update to suspend
HMI use of the communications channel.
HMI Device Overview
Select the Device Overview branch to display an overview of the relay
operation. This view includes a summary of information from many of the
other HMI branches, including fundamental metering, contact input/output
status, and front-panel LED status.
The Device Overview colors and text can be customized. White LED symbols
indicate a deasserted condition and LED symbols with any other color
indicate an asserted condition. Click an LED symbol to change its assert color.
Double-click the LED label to change the label.
HMI Control Window
Select the Control Window branch to reset metering values, clear event
records, trip and close reclosers/breakers, pulse output contacts, and set and
clear remote bits (see Figure 6.4 for an example).
Demand/Peak A table showing demand and peak demand values. This display
also allows demand and peak demand values to be reset.
Min/Max A table showing maximum/minimum metering quantities. This
display also allows maximum/minimum metering quantities to
be reset.
Energy A table showing energy import/export. This display also allows
energy values to be reset.
Targets View Relay Word bits in a row/column format.
Status A list of relay status conditions.
LDP View load profile data.
SER Sequential Events Recorder data listed oldest to newest, top to
bottom. Set the range of SER records with the dialog boxes at
the bottom of the display.
SSI View voltage Sag, Swell, and Interruption data.
Breaker Monitor Data A table showing the latest circuit breaker monitor data.
Control Window Metering and records reset buttons, trip and close control, out-
put pulsing, target reset, time and date set, group switch, and
remote bit control.
Ta b l e 6 . 4
ACSELERATOR QuickSet HMI Tree View Functions (Sheet 2 of 2)
