Sel 411L - Page 601

P.7.33
Date Code 20151029 Protection Manual SEL-411L Relay
Front-Panel Operations
Front-Panel Menus and Screens
Figure 7.39 VIEW CONFIGURATION Sample Screens
Display Test
You can use the DISPLAY TEST option of the MAIN MENU to confirm operation
of all of the LCD pixels. The LCD screen alternates the on/off state of the
display pixels once every time you press ENT. Figure 7.40 shows the resulting
two screens. The
DISPLAY TEST option also illuminates all of the front-panel
LEDs. To exit the test mode, press ESC.
FID=SEL-411L-R101-
V0-Z001001-
D20110130
PART NUMBER: 0451541
5XC0X4H60X0XXX
S/N=201101001
SELBOOT:
BFID=SLBT-4XX-
R205-V0-Z001002-
D20100130
CHECKSUM: D97F
CONFIGURATION INFO
FIBER PORT:
NOT INSTALLED
INTERFACE BOARDS:
BOARD 1: 8 INPUTS
15 OUTPUTS
BOARD 2:NOT
INSTALLED
EXTENDED FEATURES:
DNP ACTIVE
CONFIGURATION INFO
MAINBOARD:
CODE FLASH: 4 MB
DATA FLASH: 8 MB
RAM: 3 MB
EEPROM: 32 KB
ANALOG INPUTS:
W: CURRENTS: 5 A
X: CURRENTS: 5 A
Y: VOLTAGE: 67 V
Z: VOLTAGE: 67 V
CONFIGURATION INFO
IF THE CONFIGURATION
IS NOT WHAT YOU
EXPECTED, CONTACT
SEL FOR ASSISTANCE.
CONFIGURATION INFO
COMMS CONFIGURATION:
CONFIGURATION INFO
BAY 4 - RS-232/IRIG
BAY 3 - ETHERNET
PORT 5A 87L FIBER
PORT 5B 87L COPPER
PORT 5C FIBER
PORT 5D COPPER
BAY 2 - SERIAL 87L
1550 nm FIBER
BAY 1 - SERIAL 87L
1550nm FIBER
