P.16.17
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Alphabetic
ACN09Q–ACN16Q Automation Counter 9–16 output 221
ACN17Q–ACN24Q Automation Counter 17–24 output 222
ACN25Q–ACN32Q Automation Counter 25–32 output 223
ACN01R–ACN08R Automation Counter 1–8 reset 224
ACN09R–ACN16R Automation Counter 9–16 reset 225
ACN17R–ACN24R Automation Counter 17–24 reset 226
ACN25R–ACN32R Automation Counter 25–32 reset 227
AFRTEXA Automation SEL
OGIC control equation first execution after Automation Settings change 228
AFRTEXP Automation SEL
OGIC control equation first execution after Protection Settings Change, Group
Switch, or Source Switch Selection.
228
ALT01–ALT08 Automation Latch 1–8 208
ALT09–ALT16 Automation Latch 9–16 209
ALT17–ALT24 Automation Latch 17–24 210
ALT25–ALT32 Automation Latch 25–32 211
ALTI Alternate current source (SEL
OGIC control equation) 314
ALTS2 Alternate synchronism source for Circuit Breaker 2 314
ALTV Alternate voltage source (SELOGIC control equation) 314
ANOKA Analog transfer OK on Mirrored Bits communications Channel A 259
ANOKB Analog transfer OK on Mirrored Bits communications Channel B 260
APS Trip logic A-phase selected 54
AST01Q–AST08Q Automation Sequencing Timer 1–8 output 212
AST09Q–AST16Q Automation Sequencing Timer 9–16 output 213
AST17Q–AST24Q Automation Sequencing Timer 17–24 output 214
AST25Q–AST32Q Automation Sequencing Timer 25–32 output 215
AST01R–AST08R Automation Sequencing Timer 1–8 reset 216
AST09R–AST16R Automation Sequencing Timer 9–16 reset 217
AST17R–AST24R Automation Sequencing Timer 17–24 reset 218
AST25R–AST32R Automation Sequencing Timer 25–32 reset 219
ASV001–ASV008 Automation SEL
OGIC Variable 1–8 176
ASV009–ASV016 Automation SEL
OGIC Variable 9–16 177
ASV017–ASV024 Automation SEL
OGIC Variable 17–24 178
ASV025–ASV032 Automation SEL
OGIC Variable 25–32 179
ASV033–ASV040 Automation SEL
OGIC Variable 33–40 180
ASV041–ASV048 Automation SEL
OGIC Variable 41–48 181
ASV049–ASV056 Automation SEL
OGIC Variable 49 182
ASV057–ASV064 Automation SEL
OGIC Variable 57–64 183
ASV065–ASV072 Automation SEL
OGIC Variable 65–72 184
ASV073–ASV080 Automation SEL
OGIC Variable 73–80 185
ASV081–ASV088 Automation SEL
OGIC Variable 81–88 186
ASV089–ASV096 Automation SEL
OGIC Variable 89 187
ASV097–ASV104 Automation SEL
OGIC Variable 97–104 188
Table 16.1 Alphabetical List of Relay Word Bits (Sheet 17 of 39)
Name Bit Description Row
