Relay Word Bits
Alphabetic
OUT501–OUT508 Optional I/O Board 4 Output 1–8 246
OUT509–OUT516 Optional I/O Board 4 Output 9–16 247
P5ASEL Port 5A active/inactive 318
P5BSEL Port 5B active/inactive 318
P5CSEL Port 5C active/inactive 318
P5DSEL Port 5D active/inactive 318
PB_CLSE Auxiliary CLOSE Pushbutton 325
PB_TRIP Auxiliary TRIP Pushbutton 325
PB1–PB8 Pushbutton 1–8 238
PB1_LED–PB8_LED Pushbutton 1–8 LED 252
PB1_PUL–PB8_PUL Pushbutton 1–8 pulse (on for one processing interval when button is pushed) 248
PB9–PB12 Pushbutton 9–12 325
PB9_LED–PB12LED Pushbutton 9–12 LED 326
PB9_PUL–PB12PUL Pushbutton 9–12 pulse (on for one processing interval when button is pushed) 326
PCN01Q–PCN08Q Protection Counter 1–8 output 168
PCN09Q–PCN16Q Protection Counter 9–16 output 169
PCN17Q–PCN24Q Protection Counter 17–24 output 170
PCN25Q–PCN32Q Protection Counter 25–32 output 171
PCN17R–PCN24R Protection Counter 17–24 reset 174
PCN01R–PCN08R Protection Counter 1–8 reset 172
PCN09R–PCN16R Protection Counter 9–16 reset 173
PCN25R–PCN32R Protection Counter 25–32 reset 175
PCT01Q–PCT08Q Protection Conditioning Timer 1–8 output 156
PCT09Q–PCT16Q Protection Conditioning Timer 9–16 output 157
PCT17Q–PCT24Q Protection Conditioning Timer 17–24 output 158
PCT25Q–PCT32Q Protection Conditioning Timer 25–32 output 159
PDEM Phase current demand picked up 52
PF3_OK 3 phase power factor OK 127
PFA_OK A phase power factor OK 127
PFB_OK B phase power factor OK 127
PFC_OK C phase power factor OK 127
PFRTEX Protection SEL
OGIC control equation first execution 228
PHASE_A Indicates an A-phase fault 237
PHASE_B Indicates a B-phase fault 237
PHASE_C Indicates a C-phase fault 237
PLDTE Asserts for approximately 1.5 cycles when the TEC command is used to load a new time-error
correction factor (preload value) into the TECORR analog quantity.
323
PLT01–PLT08 Protection Latch 1–8 152
PLT09–PLT16 Protection Latch 9–16 153
PLT17–PLT24 Protection Latch 17–24 154
PLT25–PLT32 Protection Latch 25–32 155
