P.16.51
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
Remote Bits Start
104 RB25–RB32 Remote Bits 25–32
105 RB17–RB24 Remote Bits 17–24
106 RB09–RB16 Remote Bits 9–16
107 RB01–RB08 Remote Bits 1–8
Inverse-Time Overcurrent Elements (Continued)
108 51TC01 Inverse-time Element 01 enabled
108 51R01 Inverse-time Element 01 reset
108 51MM01 Inverse-time Element 01 pickup setting outside of specified limits
108 51TM01 Inverse-time Element 01 time dial setting outside of specified limits
108 51TC02 Inverse-time Element 02 enabled
108 51R02 Inverse-time Element 02 reset
108 51MM02 Inverse-time Element 02 pickup setting outside of specified limits
108 51TM02 Inverse-time Element 02 time dial setting outside of specified limits
109 51TC03 Inverse-time Element 03 enabled
109 51R03 Inverse-time Element 03 reset
109 51MM03 Inverse-time Element 03 pickup setting outside of specified limits
109 51TM03 Inverse-time Element 03 time dial setting outside of specified limits
109 51TC04 Inverse-time Element 04 enabled
109 51R04 Inverse-time Element 04 reset
109 51MM04 Inverse-time Element 04 pickup setting outside of specified limits
109 51TM04 Inverse-time Element 04 time dial setting outside of specified limits
110 51TC05 Inverse-time Element 05 enabled
110 51R05 Inverse-time Element 05 reset
110 51MM05 Inverse-time Element 05 pickup setting outside of specified limits
110 51TM05 Inverse-time Element 05 time dial setting outside of specified limits
110 51TC06 Inverse-time Element 06 enabled
110 51R06 Inverse-time Element 06 reset
110 51MM06 Inverse-time Element 06 pickup setting outside of specified limits
110 51TM06 Inverse-time Element 06 time dial setting outside of specified limits
111 51TC07 Inverse-time Element 07 enabled
111 51R07 Inverse-time Element 07 reset
111 51MM07 Inverse-time Element 07 pickup setting outside of specified limits
111 51TM07 Inverse-time Element 07 time dial setting outside of specified limits
111 51TC08 Inverse-time Element 08 enabled
111 51R08 Inverse-time Element 08 reset
111 51MM08 Inverse-time Element 08 pickup setting outside of specified limits
111 51TM08 Inverse-time Element 08 time dial setting outside of specified limits
112 51TC09 Inverse-time Element 09 enabled
112 51R09 Inverse-time Element 09 reset
112 51MM09 Inverse-time Element 09 pickup setting outside of specified limits
Table 16.2 Row List of Relay Word Bits (Sheet 13 of 35)
Row Name Bit Description
