P.16.70
SEL-411L Relay Protection Manual Date Code 20151029
Relay Word Bits
Row List
391 89OIM09 Disconnect 09 open immobility timer timed out
391 89CIM09 Disconnect 09 close immobility timer timed out
392 89CBL10 Disconnect 10 close block
392 89OSI10 Disconnect 10 open seal-in timer timed out
392 89CSI10 Disconnect 10 close seal-in timer timed out
392 89OIR10 Disconnect 10 open immobility timer reset
392 89CIR10 Disconnect 10 close immobility timer reset
392 89OBL10 Disconnect 10 open block
392 89ORS10 Disconnect 10 open reset
392 89CRS10 Disconnect 10 close reset
393 89OIM10 Disconnect 10 open immobility timer timed out
393 89CIM10 Disconnect 10 close immobility timer timed out
81 Frequency Elements
394 81D1 Level 1 definite-time frequency element pickup
394 81D1T Level 1 definite-time frequency element delay
394 81D1OVR Level 1 overfrequency element pick up
394 81D1UDR Level 1 underfrequency element pick up
394 27B81 Undervoltage supervision for frequency elements
395 81D2 Level 2 definite-time frequency element pickup
395 81D2T Level 2 definite-time frequency element delay
395 81D2OVR Level 2 overfrequency element pick up
395 81D2UDR Level 2 underfrequency element pick up
395 81D3 Level 3 definite-time frequency element pickup
395 81D3T Level 3 definite-time frequency element delay
395 81D3OVR Level 3 overfrequency element pick up
395 81D3UDR Level 3 underfrequency element pick up
396 81D4 Level 4 definite-time frequency element pickup
396 81D4T Level 4 definite-time frequency element delay
396 81D4OVR Level 4 overfrequency element pick up
396 81D4UDR Level 4 underfrequency element pick up
396 81D5 Level 5 definite-time frequency element pickup
396 81D5T Level 5 definite-time frequency element delay
396 81D5OVR Level 5 overfrequency element pick up
396 81D5UDR Level 5 underfrequency element pick up
397 81D6 Level 6 definite-time frequency element pickup
397 81D6T Level 6 definite-time frequency element delay
397 81D6OVR Level 6 overfrequency element pick up
397 81D6UDR Level 6 underfrequency element pick up
87L Communications Bits
398 87T1P1–87T4P1 Bits 1–4 transmitted on Serial Port 1
398 87T1P2–87T4P2 Bits 1–4 transmitted on Serial Port 2
Table 16.2 Row List of Relay Word Bits (Sheet 32 of 35)
Row Name Bit Description
