2-5
uplink: Configures the port as the uplink port of the specified Monitor Link group
downlink: Configures the port as the downlink port of the specified Monitor Link group
Description
Use the port monitor-link group command to configure the current port as a member of the specified
Monitor Link group.
Use the undo port monitor-link group command to remove the current port from the specified Monitor
Link group.
In Monitor Link, a Monitor Link group member can be a single port, a static link aggregation group, but
not a dynamic link aggregation group. Uplink port can also be a Smart Link group.
Do not use this command on member ports of a link aggregation group or a Smart Link group.
A port or a link aggregation group cannot serve as a member port for two Smart Link groups. On the
other hand, a port or a link aggregation group cannot serve as a member for a Smart Link group and a
Monitor Link group at the same time. However, a Smart Link group can serve as the uplink member port
of a Monitor Link group.
Example
# Configure Ethernet1/0/8 as a downlink port of Monitor Link group 1.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] interface Ethernet 1/0/8
[Sysname-Ethernet1/0/8] port monitor-link group 1 downlink
smart-link group
Syntax
smart-link group group-id uplink
undo smart-link group group-id
View
Monitor Link group view
Parameter
group-id: Smart Link group ID, ranging 1 to 24.
uplink: Configures the specified Smart Link group as the uplink port of the Monitor Link group
Description
Use the smart-link group command to configure the specified Smart Link group as the uplink port of
the Monitor Link group.
