1-42
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] acl number 4000
[Sysname-acl-ethernetframe-4000] rule permit source 5
[Sysname-acl-ethernetframe-4000] quit
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] traffic-remark-vlanid inbound link-group 4000 remark-vlan 1001
traffic-shape
Syntax
traffic-shape queue queue-id max-rate burst-size
undo traffic-shape queue queue-id
View
Ethernet port view
Parameter
queue queue-id: Specifies the ID of a queue, in the range of 0 to 3.
max-rate: Maximum traffic rate on a port, in kbps. It’s in the range of 64 to 100000(for 100Mbps Ethernet
ports)or 64 to 1000000(for 1000 Mbps Ethernet ports).Note that this argument must be a multiple of 64.
burst-size: Burst size (in KB), in the range 8 to 1016. This argument must be a multiple of 8.
Description
Use the traffic-shape command to enable traffic shaping and send the packets out at an even rate. Use
the undo traffic-shape command to disable traffic shaping.
By default, traffic shaping is disabled.
Related command: display qos-interface traffic-shape.
Only H3C S3100-EI series switches support this command.
Example
# Configure traffic shaping on Ethernet 1/0/1, with the maximum rate being 640 kbps and the burst size
being 16 KB.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] traffic-shape 640 16
