H3C S3100 Series Command Manual

1-11
rule (for Basic ACLs)
Syntax
rule [ rule-id ] { deny | permit} [ rule-string ]
undo rule rule-id [ fragment | source | time-range ]*
View
Basic ACL view
Parameters
Parameters of the rule command
rule-id: ACL rule ID, in the range of 0 to 65534.
deny: Drops the matched packets.
permit: Permits the matched packets.
rule-string: ACL rule information, which can be a combination of the parameters described in
Table 1-6.
Table 1-6 Parameters for basic IPv4 ACL rules
Parameters Function Description
source { sour-addr
sour-wildcard | any }
Specifies a source address.
The sour-addr sour-wildcard argument
specifies a source IP address in dotted
decimal notation. Setting the wildcard to
a zero indicates a host address. The any
keyword indicates any source IP
address.
fragment
Indicates that the rule applies
only to non-tail fragments.
––
time-range time-name
Specifies the time range in
which the rule takes effect.
time-name: specifies the name of the
time range in which the rule is active; a
string comprising 1 to 32 characters.
sour-wildcard is the complement of the wildcard mask of the source subnet mask. For example, you
need to input 0.0.255.255 to specify the subnet mask 255.255.0.0.
Parameters of the undo rule command
rule-id: Rule ID, which must the ID of an existing ACL rule. You can obtain the ID of an ACL rule by using
the display acl command.
fragment: Removes the settings concerning non-tail fragments in the ACL rule.
source: Removes the settings concerning source address in the ACL rule.
time-range: Removes the settings concerning time range in the ACL rule.
