1-3
Field Description
Loadsharing Type Load sharing type: Shar for load sharing and NonS for non-load sharing
Actor ID Local device ID
AL ID Aggregation group ID
AL Type Aggregation group type: D (dynamic), S (static), or M (manual)
Partner ID
ID of the remote device, including the system priority and system MAC
address of the remote device
For a device belonging to an dynamic aggregation group or static aggregation
group, if no LACP packet is received, the partner ID is displayed as 0x8000,
0000-0000-0000.
Select Ports Number of the selected ports
Unselect Ports Number of the unselected ports
Share Type Load sharing type: Shar (load-sharing), or NonS (non-load-sharing)
Master Port the smallest port number in an aggregation group
display link-aggregation verbose
Syntax
display link-aggregation verbose [ agg-id ]
View
Any view
Parameter
agg-id: Aggregation group ID to be displayed, which ranges from 1 to 52 and must be the ID of an
existing aggregation group.
Description
Use the display link-aggregation verbose command to display the details about a specified
aggregation group or all aggregation groups.
Note that as ports in a manual link aggregation groups do not acquire the information about their peers
automatically, so the entries in the information about the peer ports displayed are all 0 instead of the
actual values.
Example
# Display the details about aggregation group 1.
<Sysname> display link-aggregation verbose 1
Loadsharing Type: Shar -- Loadsharing, NonS -- Non-Loadsharing
Flags: A -- LACP_Activity, B -- LACP_timeout, C -- Aggregation,
D -- Synchronization, E -- Collecting, F -- Distributing,
G -- Defaulted, H -- Expired
Aggregation ID: 1, AggregationType: Static, Loadsharing Type: NonS
Aggregation Description: abc
System ID: 0x16, 0012-a990-2240
Port Status: S -- Selected, U -- Unselected
