1-47

z The VLAN-VPN tunnel function can only be enabled on STP-enabled devices.

z To enable the VLAN-VPN tunnel function, make sure the links between operator’s networks are

trunk links.

z Currently, only S3100-SI series Ethernet Switches support the VLAN-VPN tunnel feature.

Examples

# Enable the VLAN-VPN tunnel function for the switch.

<Sysname> system-view

System View: return to User View with Ctrl+Z.

[Sysname] vlan-vpn tunnel
