1-2
ReAuth Period 3600 s, ReAuth MaxTimes 2
Quiet Period 60 s, Quiet Period Timer is disabled
Supp Timeout 30 s, Server Timeout 100 s
Interval between version requests is 30s
Maximal request times for version information is 3
The maximal retransmitting times 2
EAD Quick Deploy configuration:
Url: http: //192.168.19.23
Free-ip: 192.168.19.0 255.255.255.0
Acl-timeout: 30 m
Total maximum 802.1x user resource number is 1024
Total current used 802.1x resource number is 1
Ethernet1/0/1 is link-up
802.1X protocol is enabled
Proxy trap checker is disabled
Proxy logoff checker is disabled
Version-Check is disabled
The port is an authenticator
Authentication Mode is Auto
Port Control Type is Port-based
ReAuthenticate is disabled
Max number of on-line users is 256
Authentication Success: 4, Failed: 2
EAPOL Packets: Tx 7991, Rx 14
Sent EAP Request/Identity Packets : 7981
EAP Request/Challenge Packets: 0
Received EAPOL Start Packets : 5
EAPOL LogOff Packets: 1
EAP Response/Identity Packets : 4
EAP Response/Challenge Packets: 4
Error Packets: 0
1. Authenticated user : MAC address: 000d-88f6-44c1
Controlled User(s) amount to 1
Ethernet1/0/2
……
Table 1-1 Description on the fields of the display dot1x command
Field Description
Equipment 802.1X protocol is
enabled
802.1x protocol (802.1x for short) is enabled on the switch.
CHAP authentication is enabled CHAP authentication is enabled.
DHCP-launch is disabled DHCP-triggered. 802.1x authentication is disabled.
