P.16.73
Date Code 20151029 Protection Manual SEL-411L Relay
Relay Word Bits
Row List
424 87R09P2–87R16P2 Received Bits 9–16 from Remote Peer 2
425 87R17P2–87R24P2 Received Bits 17–24 from Remote Peer 2
426 87R25P2–87R32P2 Received Bits 25–32 from Remote Peer 2
427 Future
428 87R09P3–87R16P3 Received Bits 9–16 from Remote Peer 3
429 87R17P3–87R24P3 Received Bits 17–24 from Remote Peer 3
430 87R25P3–87R32P3 Received Bits 25–32 from Remote Peer 3
Miscellaneous FID Logic
432 FTDLG Double-line-to-ground Fault detected (total current)
432 FTSABG ABG Fault (total current)
432 FTSBCG BCG Fault (total current)
432 FTSCAG CAG Fault (total current)
433 Future
434 Future
435 Future
Full-Cycle Mho and Quad Ground Distance 2
436 ENX2AG Enable A-phase Ipa polarized reactance element
436 ENX2BG Enable B-phase Ipb polarized reactance element
436 ENX2CG Enable C-phase Ipc polarized reactance element
436 CNR2AG Control A-phase Ipa polarized right blinder
436 CNR2BG Control B-phase Ipb polarized right blinder
436 CNR2CG Control C-phase Ipc polarized right blinder
436 CNR1AG Control A-phase composite current polarized right blinder
436 CNR1BG Control B-phase composite current polarized right blinder
437 CNR1CG Control C-phase composite current polarized right blinder
437 Future
Full-Cycle Mho and Phase Quad Phase Distance 2
438 ENX2AB Enable AB negative-sequence reactance element
438 ENX2BC Enable BC negative-sequence reactance element
438 ENX2CA Enable CA negative-sequence reactance element
438 CNR1AB Control AB positive-sequence right blinder
438 CNR1BC Control BC positive-sequence right blinder
438 CNR1CA Control CA positive-sequence right blinder
438 CNR2AB Control AB negative-sequence right blinder
438 CNR2BC Control BC negative-sequence right blinder
439 CNR2CA Control CA negative-sequence right blinder
439 Future
a
In 411L-1 only.
Table 16.2 Row List of Relay Word Bits (Sheet 35 of 35)
Row Name Bit Description
