P.17.11
Date Code 20151029 Protection Manual SEL-411L Relay
Analog Quantities
Quantities Listed Alphabetically
IBXPMRD Synchrophasor current real component, B-phase, Terminal X, delayed for RTC
alignment
Amperes [A] (primary)
ICD Demand C-phase current Amps [A] (primary)
ICPKD Peak demand C-phase current Amps [A] (primary)
ICSPMA Synchrophasor current angle, C-phase, Terminal S Degrees [°] (±180°)
ICSPMAD Synchrophasor current angle, C-phase, Terminal S, delayed for RTC alignment Degrees [°] (±180°)
ICSPMI Synchrophasor current imaginary component, C-phase, Terminal S Amperes [A] (primary)
ICSPMID Synchrophasor current imaginary component, C-phase, Terminal W, delayed for
RTC alignment
Amperes [A] (primary)
ICSPMM Synchrophasor current magnitude, C-phase, Terminal S Amperes [A] (primary)
ICSPMMD Synchrophasor current magnitude, C-phase, Terminal S, delayed for RTC alignment Amperes [A] (primary)
ICSPMR Synchrophasor current real component, C-phase, Terminal S Amperes [A] (primary)
ICSPMRD Synchrophasor current real component, C-phase, Terminal S, delayed for RTC
alignment
Amperes [A] (primary)
ICWDCM DC component of local Terminal W current, C-phase Per unit [pu]
ICWFA C-phase, Terminal W, filtered current, angle Degrees [°] (±180°)
ICWFI C-phase, Terminal W, filtered current, imaginary component Amps [A] (secondary)
ICWFM C-phase, Terminal W, filtered current, magnitude Amps [A] (secondary)
ICWFR C-phase, Terminal W, filtered current, real component Amps [A] (secondary)
ICWPMA Synchrophasor current angle, C-phase, Terminal W Degrees [°] (±180°)
ICWPMAD Synchrophasor current angle, C-phase, Terminal W, delayed for RTC alignment Degrees [°] (±180°)
ICWPMI Synchrophasor current imaginary component, C-phase, Terminal W Amperes [A] (primary)
ICWPMID Synchrophasor current imaginary component, C-phase, Terminal W, delayed for
RTC alignment
Amperes [A] (primary)
ICWPMM Synchrophasor current magnitude, C-phase, Terminal W Amperes [A] (primary)
ICWPMMD Synchrophasor current magnitude, C-phase, Terminal W, delayed for RTC alignment Amperes [A] (primary)
ICWPMR Synchrophasor current real component, C-phase, Terminal W Amperes [A] (primary)
ICWPMRD Synchrophasor current real component, C-phase, Terminal W, delayed for RTC
alignment
Amperes [A] (primary)
ICXDCM DC component of local Terminal X current, C-phase Per unit [pu]
ICXFA C-phase, Terminal X, filtered current, angle Degrees [°] (±180°)
ICXFI C-phase, Terminal X, filtered current, imaginary component Amps [A] (secondary)
ICXFM C-phase, Terminal X, filtered current, magnitude Amps [A] (secondary)
ICXFR C-phase, Terminal X, filtered current, real component Amps [A] (secondary)
ICXPMA Synchrophasor current angle, C-phase, Terminal X Degrees [°] (±180°)
ICXPMAD Synchrophasor current angle, C-phase, Terminal X, delayed for RTC alignment Degrees [°] (±180°)
ICXPMI Synchrophasor current imaginary component, C-phase, Terminal X Amperes [A] (primary)
ICXPMID Synchrophasor current imaginary component, C-phase, Terminal X, delayed for
RTC alignment
Amperes [A] (primary)
ICXPMM Synchrophasor current magnitude, C-phase, Terminal X Amperes [A] (primary)
ICXPMMD Synchrophasor current magnitude, C-phase, Terminal X, delayed for RTC alignment Amperes [A] (primary)
ICXPMR Synchrophasor current real component, C-phase, Terminal X Amperes [A] (primary)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 11 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
