P.17.12
SEL-411L Relay Protection Manual Date Code 20151029
Analog Quantities
Quantities Listed Alphabetically
ICXPMRD Synchrophasor current real component, C-phase, Terminal X, delayed for RTC
alignment
Amperes [A] (primary)
IGD Demand zero-sequence current Amps [A] (primary)
IGPKD Peak demand zero-sequence current Amps [A] (primary)
IPFIM Filtered instantaneous polarizing current magnitude Amps [A] (secondary)
L3I2A 10-cycle average negative-sequence current angle (line) Degrees [°] (±180°)
L3I2FIA Negative-sequence instantaneous current angle Degrees [°] (±180°)
L3I2FIM Negative-sequence instantaneous current magnitude Amps [A] (secondary)
L3I2M 10-cycle average negative-sequence current magnitude (line) Amps [A] (primary)
LI1A 10-cycle average positive-sequence current angle (line) Degrees [°] (±180°)
LI1FIA Positive-sequence instantaneous current angle Degrees [°] (±180°)
LI1FIM Positive-sequence instantaneous current magnitude Amps [A] (secondary)
LI1M 10-cycle average positive-sequence current magnitude (line) Amps [A] (primary)
LIAFA A-phase 10-cycle average fundamental current angle (line) Degrees [°] (±180°)
LIAFIA A-phase filtered instantaneous current angles Degrees [°] (±180°)
LIAFIM Filtered instantaneous A-phase current magnitude Amps [A] (secondary)
LIAFM A-phase 10-cycle average fundamental current magnitude (line) Amps [A] (primary)
LIARMS A-phase 10-cycle average rms current (line) Amps [A] (primary)
LIBFA B-phase 10-cycle average fundamental current angle (line) Degrees [°] (±180°)
LIBFIA B-phase filtered instantaneous current angles Degrees [°] (±180°)
LIBFIM Filtered instantaneous B-phase current magnitude Amps [A] (secondary)
LIBFM B-phase 10-cycle average fundamental current magnitude (line) Amps [A] (primary)
LIBRMS B-phase 10-cycle average rms current (line) Amps [A] (primary)
LICFA C-phase 10-cycle average fundamental current angle (line) Degrees [°] (±180°)
LICFIA C-phase filtered instantaneous current angles Degrees [°] (±180°)
LICFIM Filtered instantaneous C-phase current magnitude Amps [A] (secondary)
LICFM C-phase 10-cycle average fundamental current magnitude (line) Amps [A] (primary)
LICRMS C-phase 10-cycle average rms current (line) Amps [A] (primary)
LIGA 10-cycle average zero-sequence current angle (line) Degrees [°] (±180°)
LIGFIA Zero-sequence instantaneous current angle Degrees [°] (±180°)
LIGFIM Zero-sequence instantaneous current magnitude Amps [A] (secondary)
LIGM 10-cycle average zero-sequence current magnitude (line) Amps [A] (primary)
LIMAXM Filtered instantaneous maximum phase current magnitude Amps [A] (secondary)
MAB, MBC, MCA Mho phase-to-phase impedance calculation Ohms (secondary)
MAGF, MBGF,
MCGF
Forward mho ground calculation (excludes Zone 1) Ohms (secondary)
MAGR, MBGR,
MCGR
Reverse mho ground calculation (all reverse zones) Ohms (secondary)
MAGZ1, MBGZ1,
MCGZ1
Zone 1 mho ground impedance calculation Ohms (secondary)
MB1A A Channel received M
IRRORED BIT analog values NA
MB1B B Channel received M
IRRORED BIT analog values NA
Table 17.1 Alphabetical List of Analog Quantities (Sheet 12 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
