P.17.13
Date Code 20151029 Protection Manual SEL-411L Relay
Analog Quantities
Quantities Listed Alphabetically
MB2A A Channel received MIRRORED BIT analog values NA
MB2B B Channel received M
IRRORED BIT analog values NA
MB3A A Channel received M
IRRORED BIT analog values NA
MB3B B Channel received M
IRRORED BIT analog values NA
MB4A A Channel received M
IRRORED BIT analog values NA
MB4B B Channel received M
IRRORED BIT analog values NA
MB5A A Channel received M
IRRORED BIT analog values NA
MB5B B Channel received M
IRRORED BIT analog values NA
MB6A A Channel received M
IRRORED BIT analog values NA
MB6B B Channel received M
IRRORED BIT analog values NA
MB7A A Channel received M
IRRORED BIT analog values NA
MB7B B Channel received M
IRRORED BIT analog values NA
MWHAIN Negative (import) A-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHAOUT Positive (export) A-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHAT Total A-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHBIN Negative (import) B-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHBOUT Positive (export) B-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHBT Total B-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHCIN Negative (import) C-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHCOUT C-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
MWHCT C-phase energy, Megawatthrs Megawatt-hour [MWh]
(primary)
NEW_SRC Selected high accuracy time source NA
NVS1M, NVS2M Voltage magnitude Volts [V] (secondary)
PA Real A-phase power Megawatts [MW] (primary)
PA_F A-phase fundamental real power Megawatts [MW] (primary)
PAD Demand A-phase real power Megawatts [MW] (primary)
PAPKD Peak demand A-phase real power Megawatts [MW] (primary)
PB Real B-phase power Megawatts [MW] (primary)
PB_F B-phase fundamental real power Megawatts [MW] (primary)
PBD Demand B-phase real power Megawatts [MW] (primary)
PBPKD Peak demand B-phase real power Megawatts [MW] (primary)
PC Real C-phase power Megawatts [MW] (primary)
PC_F C-phase fundamental real power Megawatts [MW] (primary)
PCD Demand C-phase real power Megawatts [MW] (primary)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 13 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
