P.17.15
Date Code 20151029 Protection Manual SEL-411L Relay
Analog Quantities
Quantities Listed Alphabetically
SERDSJI Serial Port 100PPS data stream jitter µs
SEROTJF Fast converging serial port ON TIME marker jitter, coarse accuracy µs
SEROTJS Slow converging serial port ON TIME marker jitter, fine accuracy µs
SERTBTW Time between serial 100PPS pulses µs
SHOT1_1 Total number of 1st shot single-pole recloses NA
SHOT1_2 Total number of 2nd shot single-pole recloses NA
SHOT1_T Total number of single-pole reclosing shots issued NA
SHOT3_1 Total number of 1st shot three-pole recloses NA
SHOT3_2 Total number of 2nd shot three-pole recloses NA
SHOT3_3 Total number of 3rd shot three-pole recloses NA
SHOT3_4 Total number of 4th shot three-pole recloses NA
SHOT3_T Total number of three-pole recloses NA
SLIP1, SLIP2 Slip (fs1/2-fp) Hertz [Hz]
SODPM Second-of-day of the synchrophasor data packet Seconds [s]
SODPMD Second of day of the synchrophasor data packet, delayed for RTC alignment Seconds [s]
SPSHOT Present value of single-pole shot counter NA
SQUAL IRIG-B synchronization accuracy µs
TE Time error Seconds [s]
TECORR Time error correction preload value Seconds [s]
THR UTC time, hour (0–23) Hour [hr]
TLHR Local time, hour (0–23) Hour [hr]
TLMIN Local time, minute (0–59) Minutes [min]
TLMSEC Local time, milliseconds (0–999) Milliseconds [ms]
TLNSEC Local time, nanoseconds (0–999999) Nanoseconds [ns]
TLODMS Local time of day in milliseconds (0–86400000) Milliseconds [ms]
TLSEC Local time, seconds (0–59) Seconds [s]
TMIN UTC time, minute (0–59) Minutes [min]
TMSEC UTC time, milliseconds (0–999) Milliseconds [ms]
TNSEC UTC time, nanoseconds (0–999999) Nanoseconds [ns]
TODMS UTC time of day in milliseconds (0–86400000) Milliseconds [ms]
TQUAL Worst case IRIG-B clock time error Seconds [s]
TSEC UTC time, seconds (0–59) Seconds [s]
TUTC Offset from IRIG-B time to UTC time Hour [hr]
TWFLOC Traveling wave fault location result Miles [mi] or Kilometers [km]
UA A-phase apparent power Megavoltamps [MVA]
(primary)
UAD Demand A-phase apparent power Megavoltamps [MVA]
(primary)
UAPKD Peak demand A-phase apparent power Megavoltamps [MVA]
(primary)
UB B-phase apparent power Megavoltamps [MVA]
(primary)
Table 17.1 Alphabetical List of Analog Quantities (Sheet 15 of 19)
Analog Quantities Phase, Phase-to-Phase and Sequence Quantities Units
